Запчасти Case IH MXM175 (1.32.8/02[04]) - PUMPS FOR HYDRAULIC SYSTEM AND LIFT (03) - TRANSMISSION

1

5198194

SUPPORT

1шт.

2

14463681

O-RING,31.34mm ID x 3.53" Width

1шт.

3

5196548

MANIFOLD

1шт.

4

5198708

ELBOW

1шт.

5

5198995

CHECK VALVE

Parker

1шт.

5

87555079

CHECK VALVE

Faster

1шт.

6

13000690

HOSE CLAMP,32mm - 50mm, Worm Gear

2шт.

7

5196509

ELBOW

1шт.

8

5196510

HYD TUBE

Suction

1шт.

9

16043424

SCREW,Hex, M8 x 1.25 x 20mm, Cl 8.8, Full Thd

2шт.

10

14463681

O-RING,31.34mm ID x 3.53" Width

1шт.

11

13449424

STUD

M10 x 1.5 x 22

3шт.

12

12164714

NUT,M10 x 1.25, Cl 8

3шт.

13

47123798

BY-PASS VALVE

1шт.

14

82025340

RESTRICTION SWITCH

Vacuum, Serial Range: -C5240

1шт.

15

14306821

HEX SOC SCREW,M8 x 45mm, Cl 8.8

2шт.

15

16044224

BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8

4шт.

16

10730821

WASHER,Flat, 14.40mm ID x 26.00mm OD x 3.00mm, R80, ZND

2шт.

17

13555334

STUD

M14 x 28

2шт.

18

12164021

NUT,Thick Hex, M14, 1.50mm Pitch, 11.00mm High, Cl 10, ZND

2шт.

19

82028134

SWITCH ASSY

Oil Temperature

1шт.

20

87303771

PRESSURE SWITCH

Vacuum, Start Serial: D5240

1шт.

21

5185513

O-RING,1.78mm Thk x 18.77mm ID, 85 Duro

1шт.

22

81826567

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

1шт.

23

14438285

O-RING,29.5mm ID x 3.0mm

1шт.
