Запчасти Case IH MXM120 (1.91.3/02) - (VAR.766) APPLICATION OF WORK SPOT-LIGHTS ON EXTERIOR CAB HANDLE (10) - OPERATORS PLATFORM/CAB

1

82014951

WORK LAMP,Halogen, 12V, 55W, Clear

LH

1шт.

1

82014950

WORK LAMP,Halogen, 12V, 55W, Clear

RH

1шт.

2

14151590

BULB,H3, 12V, 55W

12V

2шт.

3

16044424

BOLT,Hex, M8 x 1.25 x 60mm, Cl 8.8

2шт.

4

80080681

LOCK WASHER

5/16"

2шт.

5

10903221

SCREW,Hex, M6 x 40mm, Cl 8.8

4шт.

6

353308

NUT,M6 x 1.0, Cl 8

4шт.

7

14048221

NUT,M8 x 1.25, Cl 10

2шт.

8

82008228

CLAMP

2шт.

9

82008229

CLAMP,28mm ID, 6.5mm Bolt Hole, J Type

2шт.

10

82006433

INSERT

PVC

2шт.

11

82000578

WIRE CONNECTOR,Male

2шт.
