1
247546A1
OIL SEAL,150mm ID x 180mm OD x 14.50mm W
2шт.
2
81676C1
ROLLER BEARING,109.54mm ID x 158.75mm OD x 23.02mm W
4шт.
3
365615A1
HOUSING
Includes: 4
2шт.
4
1349196C1
STUD
16шт.
5
100552A1
O-RING,215.57mm ID x 220.81mm OD x 2.62mm Thk
2шт.
6
247548A1
RING GEAR
2шт.
7
100559A1
SPECIAL RING
2шт.
8
100557A1
PLUG, DRAIN,M30 x 2
2шт.
9
905876R1
HEX SOC SCREW,Flat Hd, CSK, M8 x 20mm, Cl 10.9
4шт.
247549A1
HOUSING
consists of: 10 - 12
2шт.
10
NSS
NOT SOLD SEPARAT
HUB
1шт.
11
K395093
HEADED PIN,12mm OD x 15mm L
1шт.
12
252379A1
PIVOT
3шт.
13
247551A1
SUN GEAR
6шт.
14
353362A1
CENTERING RING
4.5 mm
16шт.
15
353361A1
LOCK BOLT
M12 x 45
16шт.
17
247555A1
CROWN WHEEL
2шт.
18
247556A1
THRUST WASHER,35.1mm ID x 45mm OD x 2.4mm Thk
6шт.
19
247557A1
RING, SNAP
RING SNAP
6шт.
20
247550A1
NEEDLE BEARING,5 mm OD x 10 mm
sets of 10
34шт.
323912A3
KIT
wheel, left, Includes: 1, 2, 3, 5 - 20, see also Figure 05-14
1шт.
323911A3
SET OF PARTS
wheel, right, Includes: 1, 2, 3, 5 - 20, see also Figure 05-14
1шт.
