1
252518A4
FRAME
1шт.
2
235327A2
SUPPORT
Weight
1шт.
3
828-20090
BOLT,Hex, M20 x 2.5 x 90mm, Cl 10.9
18шт.
4
896-11020
WASHER,22mm ID x 37mm OD x 4mm Thk
22 x 37 x 4 mm
18шт.
5
143948A3
SUPPORT
Engine
2шт.
6
175903A3
CUSHION
RUBBER BLOCK
4шт.
7
186977A1
WASHER,17mm ID x 70mm OD x 4.5mm Thk
70 x 16,5 x 4,5 mm
4шт.
8
828-12070
BOLT,Hex, M12 x 1.75 x 70mm, Cl 10.9
4шт.
9
828-16100
BOLT,Hex, M16 x 2 x 100mm, Cl 10.9
4шт.
10
896-11012
WASHER,13.5mm ID x 24mm OD x 3mm Thk
4шт.
11
1531047C1
PLUG
18,4 mm
34шт.
11b
NSS
NOT SOLD SEPARAT
Plug, Optional, N.A. Only
34шт.
