Запчасти Case IH MX240 (03-25) - FUEL LINES, MX240, MX270 (03) - FUEL SYSTEM

Схема запчастей Case IH MX240 - (03-25) - FUEL LINES, MX240, MX270 (03) - FUEL SYSTEM
6
13
12
2
15
6
5
7
16
14
16
1
4
16
6
6
3
11

Артикул

Название

Примечание

Количество

1

284735A2

HOSE,12.7mm ID x 1570mm L, SAE 30R7

1шт.

2

291260A2

CONDUIT

1500 mm (59 in)

1шт.

3

194199A1

FUEL FILTER

1шт.

4

323952A1

HOSE

445 mm (18 in) Cut From 284735A2

1шт.

5

323953A1

FUEL HOSE,27.00 mm ID x 375.00 mm

Cut From 291260A2

1шт.

6

1348264C1

HOSE CLAMP

3/8 ID

4шт.

7

REF

INSTRUCTION

Pump, See Figure 3-07

1шт.

11

292457A2

FUEL HOSE,9.53 mm ID x 1415.00 mm, SAE 30R7

Cut From 284736A2

1шт.

12

291507A2

CONDUIT

1345 mm (53 in), Cut From 291262A2

1шт.

13

REF

INSTRUCTION

Cooler, See Figure 8-01

1шт.

14

327835A1

FUEL HOSE,9.53 mm ID x 1865.00 mm, SAE 30R7

Cut From 284736A2

1шт.

15

327836A1

FUEL HOSE,16.64 mm ID x 1795.00 mm

Cut From 291262A2

1шт.

16

196252A1

CLAMP

4шт.

Выбрано товаров: 13
