Запчасти Case IH MX240 (03-12) - FUEL INJECTION PUMP, MX240, MX270, 6TAA-8304 EMISSIONS CERTIFIED ENGINE (03) - FUEL SYSTEM

Схема запчастей Case IH MX240 - (03-12) - FUEL INJECTION PUMP, MX240, MX270, 6TAA-8304 EMISSIONS CERTIFIED ENGINE (03) - FUEL SYSTEM
22
20
17
8
3
36
12
28
41
14
29
24
37
31
5
13
19
35
10
44
11
30
33
39
28
16
42
28
32
7
43
2
29
18
21
29
38
4
6
9
23

Артикул

Название

Примечание

Количество

J4010266

ACCUMULATOR

Accumulator, New, Consists Of 1 - 42

1шт.

JR4010266

REMAN-ACCUMULATOR

Accumulator, Remanufactured, N.A. Only

1шт.

JC4010266

CORE-ACCUMULATOR

1шт.

1

NSS

NOT SOLD SEPARAT

Body

1шт.

2

NSS

NOT SOLD SEPARAT

Valve, Solenoid

2шт.

3

NSS

NOT SOLD SEPARAT

Tappet

2шт.

4

NSS

NOT SOLD SEPARAT

Seal

2шт.

5

NSS

NOT SOLD SEPARAT

Plunger

2шт.

6

NSS

NOT SOLD SEPARAT

Seal

2шт.

7

NSS

NOT SOLD SEPARAT

Retainer

2шт.

8

NSS

NOT SOLD SEPARAT

Spring

2шт.

9

NSS

NOT SOLD SEPARAT

Retainer

2шт.

10

NSS

NOT SOLD SEPARAT

Plunger

2шт.

11

NSS

NOT SOLD SEPARAT

Spring

2шт.

12

NSS

NOT SOLD SEPARAT

Shim

2шт.

13

NSS

NOT SOLD SEPARAT

Seat

2шт.

14

NSS

NOT SOLD SEPARAT

Plug

2шт.

16

J330797

SEAL

1шт.

17

J867640

O-RING,0.07" Thk x 0.364" ID, -12, Cl 5, 75 Duro

1шт.

18

J347925

ELEC CONNECTOR

Includes 19

1шт.

19

NSS

NOT SOLD SEPARAT

Screen

1шт.

20

J867043

SEAL,1.78mm Thk x 10.82mm ID

1шт.

21

J417161

HARNESS

Inc. 22

1шт.

22

J417095

CABLE CLIP

1шт.

23

NSS

NOT SOLD SEPARAT

Bolt

1шт.

24

J331002

FLANGE BOLT,Hex, M10 x 1.5 x 80mm, Gr 10.9

4шт.

J4010266

ACCUMULATOR

Accumulator, New, Consists Of 1 - 42

1шт.

JR4010266

REMAN-ACCUMULATOR

Accumulator, Remanufactured, N.A. Only

1шт.

A77966

KIT

Consists Of 28, 29

6шт.

28

NSS

NOT SOLD SEPARAT

Seal

1шт.

29

NSS

NOT SOLD SEPARAT

Plug

1шт.

30

NSS

NOT SOLD SEPARAT

Seal

1шт.

31

NSS

NOT SOLD SEPARAT

Plug

1шт.

A77968

KIT

Consists Of 32, 33

4шт.

32

NSS

NOT SOLD SEPARAT

Seal

1шт.

33

NSS

NOT SOLD SEPARAT

Plug

1шт.

J4010544

ADJUSTER

Consists Of 35 - 39

1шт.

35

NSS

NOT SOLD SEPARAT

Adapter

1шт.

36

NSS

NOT SOLD SEPARAT

Guide

1шт.

37

NSS

NOT SOLD SEPARAT

Spring

1шт.

38

NSS

NOT SOLD SEPARAT

Seat, Valve

1шт.

39

J4001869

SEAL

1шт.

J800795

KIT

Consists Of 41, 42

1шт.

41

NSS

NOT SOLD SEPARAT

Sensor

1шт.

42

J4009836

WASHER

1шт.

43

J4010051

TEMPERATURE SENDER

Temperature

1шт.

44

J4010084

ADAPTER

1шт.

Выбрано товаров: 47
