Запчасти Case IH MX220 (07-09) - PARK BRAKE RELEASE (07) - BRAKES

1

283465A1

PLATE

1шт.

2

248-2164

GROMMET,1/4" ID x 7/16" Groove Dia

1шт.

3

282625A1

ROD

1шт.

4

279765A3

PISTON

1шт.

5

282624A1

SUPPORT

1шт.

6

627-8020

BOLT,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd

4шт.

7

282456A1

SPRING,21mm OD x 104mm L

1шт.

8

432-48

COTTER PIN,1/16" x 1/2"

1шт.

9

279763A1

BRAKE LEVER

1шт.

10

182220A1

GROMMET

1шт.

11

614-8016

BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd

2шт.

12

516-22127

CLAMP,12.7mm ID, 8.7mm Bolt Hole, J Type

1/2 ID

2шт.

13

638-53160

O-RING,2.65mm Thk x 16mm ID, Cl 5, 75 Duro

16 ID x 2,65

1шт.

14

REF

INSTRUCTION

Plate, See Figure 6-03

1шт.

15

136-159

HAIR PIN COTTER,Int, 3/16 x .080"

1шт.

16

169850C2

CABLE CLIP

2шт.
