Запчасти Case IH MX210 (06-55) - HUB ASSEMBLY - REAR WHEEL (06) - POWER TRAIN

435955A1

PACKAGE

Hub For 102 mm (4 in) axle, Inc. 2 - 11

1шт.

Order From Machinery Price List

1шт.

2

827-22080

BOLT,Hex, M22 x 2.5 x 80mm, Cl 10.9

20шт.

3

496-31094

WASHER,15/16" x 1 3/4" x .219", HDN

20шт.

6

405812A1

HUB

2шт.

7

405815A1

BUSHING

102 mm (4 in)

2шт.

8

228273A1

BOLT,Hex, M20 x 2.5 x 110mm, Cl 10.9

12шт.

9

396-31081

WASHER,20.63mm ID x 38.1mm OD x 5.56mm Thk

12шт.

10

A63219

KEY

3/4 x 6

2шт.

11

38-11608

LOCK PIN,1/4" x 1/2", Slotted

2шт.

12

303401A1

PLUG

6шт.

435956A1

PACKAGE

Hub For 115 mm (4-1/2 in) axle, Inc. 15 - 23

1шт.

Order From Machinery Price List

1шт.

15

827-22080

BOLT,Hex, M22 x 2.5 x 80mm, Cl 10.9

20шт.

16

496-31094

WASHER,15/16" x 1 3/4" x .219", HDN

20шт.

17

405812A1

HUB

2шт.

18

405816A1

BUSHING

115 mm (4-1/2 in)

2шт.

19

228273A1

BOLT,Hex, M20 x 2.5 x 110mm, Cl 10.9

12шт.

20

396-31081

WASHER,20.63mm ID x 38.1mm OD x 5.56mm Thk

12шт.

21

A63219

KEY

3/4 x 6

2шт.

22

38-11608

LOCK PIN,1/4" x 1/2", Slotted

2шт.

23

303401A1

PLUG

6шт.
