Запчасти Case IH MX200 (05-22) - FRONT WHEELS M.F.D., MX180, MX200, MX220 (05) - STEERING
№
Артикул
Название
Примечание
Количество
259366A1
WHEEL ASSY.
MX180, MX200, MX220, For Tires 420/85R28, 16.9R28, Includes 1 - 6
2шт.
1
188333A1
RIM
WHEEL W15L x 28
1шт.
3
240677A1
WHEEL DISC
1шт.
4
240686A1
SPECIAL BOLT,M16 x 2 x 50mm, Cl 10.9
8шт.
5
896-11016
WASHER,17.5mm ID x 30mm OD x 4mm Thk
8шт.
6
829-1416
NUT,M16, Cl 10
8шт.
259367A2
WHEEL
For Tires 600/65R28, Includes 1 - 6
2шт.
1
188350A1
RIM
WHEEL W18Lx28
1шт.
3
240677A1
WHEEL DISC
1шт.
4
240686A1
SPECIAL BOLT,M16 x 2 x 50mm, Cl 10.9
8шт.
5
896-11016
WASHER,17.5mm ID x 30mm OD x 4mm Thk
8шт.
6
829-1416
NUT,M16, Cl 10
8шт.
259368A1
WHEEL ASSY
For Tires 380/85R30, 14.9R30, Includes 1 - 6
2шт.
1
188338A1
RIM
WHEEL W13x30
1шт.
3
240677A1
WHEEL DISC
1шт.
4
240686A1
SPECIAL BOLT,M16 x 2 x 50mm, Cl 10.9
8шт.
5
896-11016
WASHER,17.5mm ID x 30mm OD x 4mm Thk
8шт.
6
829-1416
NUT,M16, Cl 10
8шт.
259369A1
WHEEL ASSY.
MX180, MX200, MX220, For Tires 480/70R30, 420/90R30, 16.9R30, Includes 1 - 6
2шт.
1
188341A1
RIM
WHEEL wheel, DW15L x 30
1шт.
3
240677A1
WHEEL DISC
1шт.
4
240686A1
SPECIAL BOLT,M16 x 2 x 50mm, Cl 10.9
8шт.
5
896-11016
WASHER,17.5mm ID x 30mm OD x 4mm Thk
8шт.
6
829-1416
NUT,M16, Cl 10
8шт.
259372A1
WHEEL ASSY.
For Tires 380/85R34, 14.9R34, Inc. 1 - 6
2шт.
1
231998A1
RIM
WHEEL W13x34
1шт.
3
259373A1
WHEEL DISC
1шт.
4
240686A1
SPECIAL BOLT,M16 x 2 x 50mm, Cl 10.9
8шт.
5
896-11016
WASHER,17.5mm ID x 30mm OD x 4mm Thk
8шт.
6
829-1416
NUT,M16, Cl 10
8шт.
259370A1
WHEEL ASSY.
For Tires 480/70R34, 540/65R34, Includes 1 - 6
2шт.
1
259416A1
RIM
WHEEL W15Lx34
1шт.
3
259373A1
WHEEL DISC
1шт.
4
240686A1
SPECIAL BOLT,M16 x 2 x 50mm, Cl 10.9
8шт.
5
896-11016
WASHER,17.5mm ID x 30mm OD x 4mm Thk
8шт.
6
829-1416
NUT,M16, Cl 10
8шт.
297354A1
WHEEL
MX180, MX200, MX220, W10x38, For Tires 320/85R38, Inc.1 - 6
2шт.
1
297355A1
RIM
WHEEL W10x38
1шт.
3
297356A1
DISC
1шт.
4
240686A1
SPECIAL BOLT,M16 x 2 x 50mm, Cl 10.9
8шт.
5
896-11016
WASHER,17.5mm ID x 30mm OD x 4mm Thk
8шт.
6
829-1416
NUT,M16, Cl 10
8шт.
347616A1
WHEEL
W12x38, For Tires 380/80R38, Inc. 1 - 6
2шт.
1
347618A1
RIM
WHEEL W12x38
1шт.
3
297356A1
DISC
1шт.
4
240686A1
SPECIAL BOLT,M16 x 2 x 50mm, Cl 10.9
8шт.
5
896-11016
WASHER,17.5mm ID x 30mm OD x 4mm Thk
8шт.
6
829-1416
NUT,M16, Cl 10
8шт.
10
A20058
VALVE STEM
2шт.
Выбрано товаров: 49
