Артикул
Название
Примечание
Количество
1
82030383
VALVE SECTION
ASSY
1шт.
82030383R
REMAN-HYD VALVE
MAXXUM 100, MAXXUM 110, MAXXUM 115, MAXXUM 120, MAXXUM 125, MAXXUM 130, MAXXUM 140, All (1/07-)
1шт.
82030383C
CORE-VALVE HYD
Return Number
1шт.
47367743R
REMAN-HYD VALVE
MAXXUM 100, MAXXUM 110, MAXXUM 115, MAXXUM 120, MAXXUM 125, MAXXUM 130, MAXXUM 140, All TRACTOR (1/07-), Reman for New PN 82030383
1шт.
47367743C
CORE-VALVE HYD
Return Number
1шт.
2
87568641
BRACKET
1шт.
3
16043821
SCREW,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
3шт.
4
14420371
SCREW,M10 x 35mm, Cl 12.9
M10x35
2шт.
4
14420574
HEX SOC SCREW,M10 x 45mm, Cl 12.9
1шт.
6
16100811
NUT,Hex, M8, 6.80mm, Cl 8, ZND
3шт.
7
11701721
NUT,M10, Cl 10
3шт.
9
5165897
SEALING WASHER,22.7mm ID x 30mm OD x 2mm Thk
4шт.
10
82036909
FLEXIBLE HOSE,6.35mm ID x 1880mm L, SAE 100R2
MMV Load Sense, 1880MM
1шт.
11
82034041
FLEXIBLE HOSE,15.88mm ID x 750mm L, SAE 100R2
MMV Return, 680MM
1шт.
12
87308082
FLEXIBLE HOSE,15.88mm ID x 2000mm L, SAE 100R2
MMV Feed, 1660MM
1шт.
13
82001041
CABLE TIE,0.190" x 7.00" / 200 mm L
CABLE STRAP
3шт.
14
82034043
HYD CONNECTOR
13/16"-16 UN-2A/M22x1.5
1шт.
15
14438085
O-RING,19.3mm ID x 2.4mm
1шт.
16
5185511
O-RING,1.78mm Thk x 12.42mm ID, 85 Duro
M12.42 ID x 1.78 Thk
2шт.
17
82034042
ELBOW
1-3/16"-12 UN-2A/M27x2
1шт.
18
5185513
O-RING,1.78mm Thk x 18.77mm ID, 85 Duro
1шт.
19
14438185
O-RING,24mm ID x 3mm
1шт.
20
82034044
ELBOW
13/16"-16
1шт.
21
82016839
HYD CONNECTOR,Straight, M10 x 1 ORFS, 9/16"-18" ORB
9/16"-18 UN-2A/M10x1
1шт.
22
81844850
O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro
3шт.
24
82018814
CHECK VALVE,9/16" - 18 JIC x 9/16" - 18 ORFS x 9/16" - 18 ORFS
1шт.
3 Mid Mounted Valves for MDC, VAR.331562
1шт.
25
81827528
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
2шт.
26
5185045
HYD CONNECTOR
9/16"-18, M12x1.5
1шт.
28
14437685
O-RING,9.30mm ID x 2.40mm
1шт.
29
47123020
PLUG,Hex
13/16 - 16
1шт.
29
83987627
CAP,1-14UN-2A
1" - 14
1шт.
Выбрано товаров: 36
