Запчасти Case IH MAXXUM 135 (21.507.AD[02]) - VAR - 396247, 758442, 758549 - HYDROSTATIC PUMP (21) - TRANSMISSION

1

14305021

HEX SOC SCREW,M6 x 10mm, Cl 8.8, Full Thd

2шт.

2

12649601

WASHER,6.15mm ID x 11.5mm OD x 2.5mm Thk

2шт.

3

10441190

CLAMP,8mm, Coat, 7mm Bolt Hole, P Type

2шт.

4

14314721

SCREW,M16 x 1.5 x 90mm

5шт.

5

47714391

HYDROSTATIC PUMP

1шт.

6

9823349

O-RING,0.139" Thk x 9.484" ID, -272, Cl 5, 75 Duro

1шт.

7

86579680

HYD CONNECTOR,1"-14 ORFS x M22 x 1.5mm ORB

ASSY, Incl 8, 9, 11

1шт.

8

9992069

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

1шт.

9

86598102

O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro

1шт.

10

84565818

TUBE

1шт.

11

NSS

NOT SOLD SEPARAT

Connector, Incl in 7

1шт.

12

87331111

HEX SOC SCREW,M8 x 16mm, Cl 8.8

2шт.

13

14453280

O-RING,0.07" Thk x 0.551" ID, -15, Cl 5, 75 Duro

3шт.

14

47529573

TUBE

1шт.

15

84304518

SNAP RING,1mm Thk

2шт.

16

87630110

BUSHING,17mm ID x 21mm OD x 10.7mm L

2шт.

17

47798576

GEARBOX

Transmission ASSY, Incl 1 - 16

1шт.

See all the Included Components by Searching for the PN 47798576

1шт.
