(21.505.AG[01]) - VAR - 396247, 758442, 758549 - TRANSMISSION CONTROL, DISCHARGE, VALVE, MOUNTING

Запчасти Case IH MAXXUM 135 (21.505.AG[01]) - VAR - 396247, 758442, 758549 - TRANSMISSION CONTROL, DISCHARGE, VALVE, MOUNTING (21) - TRANSMISSION

Схема запчастей Case IH MAXXUM 135 - (21.505.AG[01]) - VAR - 396247, 758442, 758549 - TRANSMISSION CONTROL, DISCHARGE, VALVE, MOUNTING (21) - TRANSMISSION
21.505.ag (02)
1
2
3
21.504.ak (01)
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

47582307

HYDRAULIC MANIFOLD

ASSY

1шт.

2

14309221

HEX SOC SCREW,M6 x 65mm, Cl 8.8

2шт.

3

47798576

GEARBOX

Transmission ASSY, Incl 1 - 2

1шт.

See all the Included Components by Searching for the PN 47798576

1шт.

Выбрано товаров: 4
