Запчасти Case IH MAXXUM 120 (88.100.35[18]) - DIA KIT - 2 ELECTRONIC MID MOUNTED VALVES - PILOT PIPES (88) - ACCESSORIES

Схема запчастей Case IH MAXXUM 120 - (88.100.35[18]) - DIA KIT - 2 ELECTRONIC MID MOUNTED VALVES - PILOT PIPES (88) - ACCESSORIES
12
15
11
14
10
3
18
11
9
4
17
12
14
12
1
5
2
home
8
21.103.ao 01
88.100.35 16
7
13
16
10
13
6

Артикул

Название

Примечание

Количество

1

719763034

DIA KIT, TRACTOR

Electronic Mid Mount Valve, 2 slice,Incl 2 - 18 and Parts on Figures 88.100.35 16 and 17

1шт.

Refer to Installation Instruction for Correct Assembly Procedure

1шт.

2

86579672

HYD CONNECTOR,11/16"-16 ORFS x M16 x 1.5 ORB

Incl 3, 4, 12

1шт.

3

86598100

O-RING,2.2mm Thk x 13.3mm ID, Cl 6, 90 Duro

1шт.

4

NSS

NOT SOLD SEPARAT

Connector, Incl in 2

1шт.

5

84467247

HYD TUBE

Discharge Servo

1шт.

6

84467241

FLEXIBLE HOSE

Load Sensing

1шт.

7

87582905

ORIFICE

1шт.

8

84467244

HYD TUBE

Supply Servo

1шт.

9

84268307

NUT,M6 x 0.75, 8 ZND

1шт.

10

84479191

CLAMP BRACKET

2шт.

11

86580178

ELBOW,90 Deg, 11/16-16 ORFS x M12 x 1.5 ORB

Incl 12 - 14

2шт.

12

9993141

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

3шт.

13

NSS

NOT SOLD SEPARAT

Elbow, Incl in 11

2шт.

14

86598098

O-RING,2.2mm Thk x 9.3mm ID, Cl 6, 90 Duro

2шт.

15

84432241

90 ELBOW,90 Degree, 9/16"-18 ORFS x M14 x 1.5 ORB

Incl 16 - 18

2шт.

16

9825770

O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro

1шт.

17

NSS

NOT SOLD SEPARAT

Elbow, Incl in 15

1шт.

18

86598099

O-RING,2.2mm Thk x 11.3mm ID, Cl 6

1шт.

Выбрано товаров: 19
