Запчасти Case IH MAXXUM 115 (33.220.AM[02]) - VAR - 744784 - TRAILER BRAKE VALVE (33) - BRAKES & CONTROLS

1

5192069

BRAKE VALVE

ASSY

1шт.

2

47666121

PIPE

Supply from Trailer Brake Valve

1шт.

3

47671615

BRACKET

1шт.

4

44015354

QUICK MALE COUPLING

1шт.

5

81863437

HYD CONNECTOR,M18 x 13/16"-16 ORS

1шт.

6

14306521

HEX SOC SCREW,M8 x 1.25 x 30mm, Cl 8.8

1шт.

7

10261060

SEALING WASHER,12.2mm ID x 16mm OD x 1.5mm Thk

1шт.

8

10300511

PLUG,M12 x 1.5 x 12, Cl5.8

1шт.

9

14359421

HEX SOC SCREW,M8 x 75mm, Cl 8.8

2шт.
