(25.100.AV[06]) - VAR - 743699, 743700 - 4WD FRONT AXLE, W/ FRONT HYDRAULIC LIFT, SUPPORT, ATTACHMENT

Запчасти Case IH MAXXUM 115 (25.100.AV[06]) - VAR - 743699, 743700 - 4WD FRONT AXLE, W/ FRONT HYDRAULIC LIFT, SUPPORT, ATTACHMENT (25) - FRONT AXLE SYSTEM

Схема запчастей Case IH MAXXUM 115 - (25.100.AV[06]) - VAR - 743699, 743700 - 4WD FRONT AXLE, W/ FRONT HYDRAULIC LIFT, SUPPORT, ATTACHMENT (25) - FRONT AXLE SYSTEM
25.100.av (04)
1
3
1
2
2
4
3
10.001.ad
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

82029234

BOLT,Hex, M20 x 1.5 x 125mm, Cl 12.9

6шт.

2

82028022

WASHER,M8 x 1.25 ID x 40mm OD x 9mm Thk, CRLC or HRLC Steel

6шт.

3

87301866

STUD,M20 x 1.5 x 170mm, Cl 10.9

M20 x 1.5

2шт.

4

87312644

NUT,Hex, M20, 1.5 Pitch, 16mm High, Gr R12

2шт.
