Запчасти Case IH MAXXUM 110 (1.32.8[01]) - PUMPS FOR HYDRAULIC SYSTEM AND LIFT (63 L/MIN) (03) - TRANSMISSION

1

14471380

O-RING,0.21" Thk x 2.1" ID, -330, Cl 5, 75 Duro

1шт.

2

47128297

TUBE

1шт.

3

87647137

BOLT,Hex, M8 x 1.25 x 29mm, Cl 8.8

1шт.

4

14464480

O-RING,0.139" Thk x 1.984" ID, -226, Cl 5, 75 Duro

2шт.

5

47123333

SUPPORT

1шт.

6

10119040

PLUG,M27 x 2 x 20, Brass

1шт.

7

14438185

O-RING,24mm ID x 3mm

1шт.

8

5153030

BLEED SCREW,Bleeder, Hex, M8 x 1.25 x 25mm

1шт.

9

47129062

PLATE

1шт.

10

12164714

NUT,M10 x 1.25, Cl 8

3шт.

11

13449521

STUD

M10 x 15 x 22

3шт.

12

14458281

O-RING,1.237" ID x 1.443" OD x 0.103"

1шт.

13

5192915

FITTING

1шт.

14

84248043

HYDRAULIC OIL FILTER,136mm OD x 244mm L, 1" 3/4-16 UN-2B

1шт.

15

16044524

SCREW,Hex, M8 x 1.25 x 65mm, Cl 8.8

4шт.

16

13000790

HOSE CLAMP,40mm - 60mm, Worm Gear

2шт.

17

87332998

TUBE

1шт.

18

14496607

WASHER,10.5mm ID x 21mm OD x 2mm Thk

10 x 21

1шт.

19

14306321

HEX SOC SCREW,M8 x 20mm, Cl 8.8

1шт.

20

87333026

MANIFOLD

1шт.

21

87333106

HOSE,45mm ID x 50mm L

1шт.
