Запчасти Case IH MAXXUM 110 (50.100.AQ[07]) - VAR - 330643 - A/C & HEATER HOSES - 4CYL (50) - CAB CLIMATE CONTROL

1

84474725

TUBE

1шт.

2

82019905

HOSE CLAMP,22 - 26mm X 12mm

2шт.

3

47577063

TUBE

1шт.

4

86511324

WASHER,13mm ID x 24mm OD x 2.5mm Thk

1шт.

5

11112121

SCREW,Hex, M12 x 20mm, Cl 8.8, Full Thd

1шт.

6

11115321

SCREW,Hex, M14 x 25mm, Cl 8.8, Full Thd

1шт.

7

14496901

WASHER,17mm ID x 30mm OD x 3mm Thk

1шт.

8

15859421

BOLT,Hex, M16 x 20mm, Cl 8.8, Full Thd

1шт.
