Запчасти Case IH MAXXUM 110 (33.110.AJ[01]) - VAR - 330709, 332709, 333709, 390709 - HAND BRAKE, LEVER (33) - BRAKES & CONTROLS

1

84174329

BRAKE LEVER

ASSY, Incl 2 - 9

1шт.

2

NSS

NOT SOLD SEPARAT

Brake Lever, Incl in 1

1шт.

3

82000812

PIN,7.8mm OD x 7.4mm L

2шт.

4

81866090

HANDLE GRIP

1шт.

5

81870377

BUTTON

1шт.

6

84199076

SPRING,11.25mm OD x 44.5mm L

1шт.

7

81866092

WASHER,5.5mm ID x 13.4mm OD x 1.2mm Thk

1шт.

8

82863025

PAWL,4.5mm Thk

1шт.

9

84174325

SUPPORT

1шт.

10

11106224

SCREW,Hex, M10 x 25mm, Cl 8.8, Full Thd

2шт.

11

14496601

WASHER,10.5mm ID x 21mm OD x 2mm Thk

2шт.

12

84140224

CLEVIS

1шт.

13

83902558

PIN,3/8" x 1.312"

1шт.

14

81813880

COTTER PIN,3/32" x 3/4"

1шт.

15

82000974

NUT,Adj., M8, 1.25 Pitch, 23.00mm High, Zinc

1шт.

16

16100811

NUT,Hex, M8, 6.80mm, Cl 8, ZND

1шт.

17

84140203

BOWDEN CONTROL

1шт.

18

84199077

PROTECTION PLATE

1шт.
