Запчасти Case IH MAXXUM 100 (1.75.0/10) - TUBES FOR FRONT HPL FROM MECHANICAL REMOTE VALVES - VALVE (VAR.330926) (06) - ELECTRICAL SYSTEMS

Схема запчастей Case IH MAXXUM 100 - (1.75.0/10) - TUBES FOR FRONT HPL FROM MECHANICAL REMOTE VALVES - VALVE (VAR.330926) (06) - ELECTRICAL SYSTEMS
4
5
5
7
6
3
2
8
1.81.9/09
9
1
3
4

Артикул

Название

Примечание

Количество

1

87603042

SUPPORT

1шт.

2

47057659

HYD TUBE

1шт.

3

5185524

HYD CONNECTOR

2шт.

4

5185512

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

1шт.

5

5135738

O-RING,0.103" Thk x 0.674" ID, -115, 80 Duro

1шт.

6

10903724

BOLT,M6 x 55, 8.8

2шт.

7

5141295

SOLENOID VALVE

1шт.

8

9824259

WASHER,6.4mm ID x 12mm OD x 1.6mm Thk

2шт.

9

86500688

NUT,Hex, M6 x 1.0, Cl 10.9

2шт.

Выбрано товаров: 9
