Запчасти Case IH 5250 (4-054) - HEADLIGHTS (04) - ELECTRICAL SYSTEMS

1

1964881C2

HEADLIGHT

LIGHT - head, without bulb, right, Includes Ref: 2-4

1шт.

2

1983288C1

RETAINER

- bulb

1шт.

3

1983287C2

GASKET

- seal

1шт.

4

1983289C1

CLIP

ADJUSTER - thumb wheel

1шт.

5

1964882C2

HEADLIGHT

LIGHT - head, without bulb, left, Includes Ref: 6-8

1шт.

6

1983288C1

RETAINER

- bulb

1шт.

7

1983287C2

GASKET

- seal

1шт.

8

1983289C1

CLIP

ADJUSTER - thumb wheel

1шт.

9

91967C1

BULB

- light, 12 volt

2шт.

10

895-11006

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

6шт.

11

829-1306

NUT,M6, Cl 10

- hex, 6 mm - 1.0

6шт.

12

892-11006

LOCK WASHER,M6

WASHER, LOCK, M6

6шт.

13

NSS

NOT SOLD SEPARAT

SEAL - headlight, 105 mm (Cut From 1531989C1 Bulk Length)

2шт.

1531989C1

RUBBER SEAL

STRIP - seal, 1486 mm, Bulk Length

1шт.
