Артикул
Название
Примечание
Количество
222395A1
DRIVER SEAT
SEAT - Cloth, Class 4, Air Suspension (See Figure 9-144), Includes: Ref. 1 - 17
1шт.
241198A1
SEAT SUPPORT
KIT - seat swivel, Includes: Ref. 1 - 8
1шт.
1
1343857C1
LARGE PLATE
PLATE - swivel
1шт.
2
1343859C1
RETAINER
- swivel
1шт.
3
1343860C1
PLATE
PLATE - swivel bearing
1шт.
4
211-1016
BALL,12.7mm OD, Gr 24
- chrome alloy steel, 1/2 inch, Class 24
8шт.
5
A49555
LARGE PLATE
RETAINER - ball
1шт.
6
1343858C1
LARGE PLATE
PLATE - swivel
1шт.
7
413-620
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
- hex, 3/8 NC x 1-1/4 inch, Class 5
4шт.
8
230-4216
LOCK NUT,3/8"-16, GA
NUT - hex, self-locking, 3/8 inch NC
4шт.
9
413-516
BOLT,Hex, 5/16" - 18 x 1", Gr 5
- hex, 5/16 NC x 1 inch, Class 5
4шт.
10
230-4225
LOCK NUT,5/16"-18, GA
NUT - hex, self-locking, 5/16 inch NC
4шт.
11
1343862C2
ROD, ADJUSTMENT
ROD - swivel
1шт.
12
NSS
NOT SOLD SEPARAT
KNOB - control, swivel
1шт.
13
N8680
SPRING
-
1шт.
14
1343861C1
SUPPORT
BRACKET - swivel rod
1шт.
15
49-36
RIVET,Truss Hd, 3/16" x 3/8"
- truss head, 3/16 x 3/8 inch
2шт.
16
413-524
BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 5
- hex, 5/16 NC x 1-1/2 inch, Class 5
4шт.
17
1974732C1
WASHER
- flat, 25/64 x 1-1/8 x 1/8 inch
4шт.
Выбрано товаров: 19
