Запчасти Case IH 5150 (9G-104) - HITCH CONTROL (09) - CHASSIS/ATTACHMENTS

1

1964848C1

SWITCH, THREE POINT

4шт.

2

T103902

HOLDER

2шт.

3

T103903

GASKET

2шт.

4

1534966C1

COVER

2шт.

5

3405478R1

SELF-TAP SCREW,Pan Hd, M4.2 x 16

4.2 x 16 mm

8шт.

6

T103906

IDEOGRAM

90137, Safety, Right

1шт.

7

T104077

IDEOGRAM

90137, Safety, Left

1шт.

8

132000A1

SUPPORT ASSY.

90133, Left

1шт.

9

131999A1

SUPPORT ASSY.

90133, Right

1шт.

10

854-10020

BOLT,Hvy Hex, M10 x 20mm, Cl 10.9

4шт.

11

100016

NUT,M10 x 1.5, Cl 8

4шт.

12

1987622C2

HARNESS

40180, Hitch Control

1шт.

13

934281R1

WASHER,M10.5 ID x 20 OD x 2 Thk

4шт.
