Запчасти Case IH MAGNUM 340 (27.106.AC[01]) - VAR - 429330 - POWERSHIFT - TRANSMISSION DIFFERENTIAL HD (27) - REAR AXLE SYSTEM

Схема запчастей Case IH MAGNUM 340 - (27.106.AC[01]) - VAR - 429330 - POWERSHIFT - TRANSMISSION DIFFERENTIAL HD (27) - REAR AXLE SYSTEM
18
22
25
11
7
16
27.106.ac 02
17
4
7
3
23
19
7
5
15
14
26
16
21
17
2
24
4
19
13
12
27.106.ac 02
10
8
6
9
21
2
20
1

Артикул

Название

Примечание

Количество

1

47460987

SPACER,74mm ID x 100mm OD x 22mm L

HD Final Drive Pinion, Powershift

1шт.

2

84541581

SHIM,335mm ID x 422mm OD x 0.08mm Thk

Differential Bearing

2шт.

2

84541582

SHIM,335mm ID x 422mm OD x 0.1mm Thk

Differential Bearing

2шт.

2

84541583

SHIM,335mm ID x 422mm OD x 0.13mm Thk

Differential Bearing

2шт.

2

84541584

SHIM,335mm ID x 422mm OD x 0.3mm Thk

Differential Bearing

2шт.

2

84541585

SHIM,335mm ID x 422mm OD x 0.76mm Thk

Differential Bearing

2шт.

3

84567697

SHIM,236mm ID x 310mm OD x 0.08mm Thk

Pinion Setting

1шт.

3

84567698

SHIM,236mm ID x 310mm OD x 0.1mm Thk

Pinion Setting

1шт.

3

84567699

SHIM,236mm ID x 310mm OD x 0.13mm Thk

Pinion Setting

1шт.

3

84567700

SHIM,236mm ID x 310mm OD x 0.3mm Thk

Pinion Setting

1шт.

3

84569646

SHIM,236mm ID x 310mm OD x 0.5mm Thk

Pinion Setting

1шт.

4

628-16040

BOLT,Hex, M16 x 2 x 40mm, Cl 10.9, Full Thd

6шт.

5

84405128

HEX SOC SCREW,M10 x 1.5 x 20mm, Cl 10.9

4шт.

6

238-6015

O-RING,0.07" Thk x 0.551" ID, -15, Cl 6, 90 Duro

1шт.

7

896-12016

WASHER,17.5mm ID x 30mm OD x 4mm Thk

14шт.

8

86629586

90 ELBOW,9/16" - 18 JIC x 9/16" - 18 Fem Sw

1шт.

9

47361617

TUBE

Pinion Lube Jumper

1шт.

10

84563439

TUBE

Differential Lock Pressure

1шт.

11

238-6013

O-RING,0.07" Thk x 0.426" ID, -13, Cl 6, 90 Duro

1шт.

12

238-5115

O-RING,0.103" Thk x 0.674" ID, -115, Cl 5, 75 Duro

1шт.

13

844-8012

BOLT,M8 x 1.25 x 20.1mm, Cl 8.8

1шт.

14

828-16055

BOLT,Hex, M16 x 2 x 55mm, Cl 10.9

8шт.

15

123869R1

ROLLER BEARING,95.263 mm ID x 36.535 mm

1шт.

16

139059C1

SEAL,70mm ID x 90mm OD x 8mm Thk

2шт.

17

139060C2

SEAL,82.6mm ID x 88.6mm OD x 4.5mm Thk

Differential Bearing Seal

2шт.

18

47511869

BEARING CARRIER

Differential, RH, Incl 19 - 21

1шт.

19

86978768

DOWEL,M12 x 30mm L

3шт.

20

NSS

NOT SOLD SEPARAT

BEARING CARRIER, Incl in 18

1шт.

21

87520608

EXPANSION PLUG,8mm

5шт.

22

47390228

CARRIER

Differential and Brake, LH, Incl 19, 21, 23

1шт.

23

NSS

NOT SOLD SEPARAT

BEARING CARRIER, Incl in 22

1шт.

24

253932A1

ROLLER BEARING,119.99mm ID x 37.98mm W

1шт.

25

47406567

TUBE

Mesh Lube

1шт.

26

47422828

SHIELD

Differential Oil

1шт.

Выбрано товаров: 34
