Запчасти Case IH MAGNUM 280 (55.510.BP[04]) - VAR - 420010, 420012, 449112, 449058, 449059, 429373, 429374 - WIRE HARNESS, CAB MAIN - BSN - ZERF08099 (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH MAGNUM 280 - (55.510.BP[04]) - VAR - 420010, 420012, 449112, 449058, 449059, 429373, 429374 - WIRE HARNESS, CAB MAIN - BSN - ZERF08099 (55) - ELECTRICAL SYSTEMS
26
6
17
18
28
7
12
14
8
30
22
15
33
27
21
1
2
9
16
10
13
25
55.510.bp 03
24
3
5
34
4
32
20
29
11
19
23
31

Артикул

Название

Примечание

Количество

1

47650192

WIRE HARNESS

Cab Main, Incl 2 - 34

1шт.

2

82015694

ELEC CONNECTOR

CPC Series 3-way, X-269 Aux Power (RH Console)

1шт.

2

298245A1

CONTACT

CPC Series

3шт.

2

87715492

CAP

CPC Sealing, Size 17

1шт.

3

87516075

MULTIPOLE CONNECTOR,Male, 9 Pole

HD10 Series 9-way, X-174 Can Tractor Diagnostics

1шт.

3

87695623

ELEC. TERMINAL PIN

Size 16

8шт.

3

84074633

COVER

Protective Cover, HD10 9-way

1шт.

4

87516075

MULTIPOLE CONNECTOR,Male, 9 Pole

HD10 Series 9-way, X-443 Can Second Diagnostics

1шт.

4

87695623

ELEC. TERMINAL PIN

Size 16

4шт.

4

84074633

COVER

Protective Cover, HD10 9-way

1шт.

5

223690A1

CONNECTOR, ELEC

DTM Series 12-way, X-421 To CODI Jumper Harness

1шт.

5

87696141

TERMINAL

Size 20

10шт.

6

84817101

ELEC CONNECTOR,Male, 16 - 20 SAE

DTM Series 3-way, X-420 Autoguidance Power To CODI

1шт.

6

87696141

TERMINAL

Size 20

3шт.

6

84817102

LOCKING TAB,Wedge Lock, 3-Pin

Wedge Lock, 3-way

1шт.

7

87694714

ELEC CONNECTOR,Female, 6 Cavities

Metri-Pack .150 6-way, X-276M To Active Terminator

1шт.

7

87688852

ELEC. TERMINAL PIN

Metri-Pack .150 Female

6шт.

7

87694719

LOCKING TAB,Wedge Lock

Gray Secondary Lock, 6-way

1шт.

8

87694154

CONTACT HOUSING,Male, 4 Pole

DT Series 4-way, X-278 Active Terminator Jumper

1шт.

8

87695623

ELEC. TERMINAL PIN

Size 16

4шт.

8

87694145

ELEC CONNECTOR

Wedge Lock, 4-way

1шт.

9

87694153

CONTACT HOUSING,Female, 4 Cavities

DT Series 4-way, X-278A Active Terminator Jumper

1шт.

9

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

Size 16 Female

4шт.

9

84074640

LOCKING TAB,Wedge Lock

Wedge Lock, 4-way

1шт.

10

87694153

CONTACT HOUSING,Female, 4 Cavities

DT Series 4-way, X-098A RH Side Wiper Motor

1шт.

10

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

Size 16 Female

3шт.

10

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

Size 16 Female

1шт.

10

84074640

LOCKING TAB,Wedge Lock

Wedge Lock, 4-way

1шт.

11

84398827

WIRE CONNECTOR

Metri-Pack .280 3-way, X-510 Luxury Cab Power Outlet 1

1шт.

11

87693727

ELEC. TERMINAL PIN,Tin, 0.75 - 1.00mm

Metri-Pack .280 Female

2шт.

11

84178477

RETAINER

Blue Secondary Lock, 3-way

1шт.

12

82944116

ELEC CONNECTOR

Positive Mate 4-way, X-513 Luxury Cab Power Outlet 4

1шт.

12

82014499

TERMINAL CONNECTOR

Posi-Mate

3шт.

13

84398827

WIRE CONNECTOR

Metri-Pack .280 3-way, X-511 Luxury Cab Power Outlet 2

1шт.

13

87693727

ELEC. TERMINAL PIN,Tin, 0.75 - 1.00mm

Metri-Pack .280 Female

2шт.

13

84178477

RETAINER

Blue Secondary Lock, 3-way

1шт.

14

82944116

ELEC CONNECTOR

Positive Mate 4-way, X-514 Luxury Cab Power Outlet 5

1шт.

14

82014499

TERMINAL CONNECTOR

Posi-Mate

3шт.

15

84398827

WIRE CONNECTOR

Metri-Pack .280 3-way, X-512 Luxury Cab Power Outlet 3

1шт.

15

87693727

ELEC. TERMINAL PIN,Tin, 0.75 - 1.00mm

Metri-Pack .280 Female

2шт.

15

84178477

RETAINER

Blue Secondary Lock, 3-way

1шт.

16

NSS

NOT SOLD SEPARAT

TERMINAL M8 Ring, X-676 RH Fender Inside Ground, Incl in 1

1шт.

17

84478446

ELEC CONNECTOR

Metri-Pack .630 2-way, X-131A Cigar Lighter

1шт.

18

279658A1

CONNECTOR, ELEC

Fastin-Faston .250 1-way, X-131B Cigar Lighter Lamp

1шт.

18

87708753

TERMINAL

Fastin-Faston .250 Female

1шт.

19

375601A1

CONNECTOR, ELEC

JPT 10-way, X-130 Power Mirror Switch

1шт.

19

87697644

TERMINAL CONNECTOR

Junior Timer Receptacle

7шт.

20

87426885

CONNECTOR, ELEC

10-way, X-122 Rear Wiper Switch

1шт.

20

87697756

TERMINAL

Metri-Pack .630 Female

2шт.

20

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Metri-Pack .630

1шт.

21

87426882

CONNECTOR, ELEC

10-way, X-398 Defog Switch

1шт.

21

87697756

TERMINAL

Metri-Pack .630 Female

4шт.

22

87426892

CONNECTOR, ELEC

10-way, X-123 Auto A/C Switch

1шт.

22

87697756

TERMINAL

Metri-Pack .630 Female

3шт.

23

87692858

ELEC CONNECTOR,Male

Weather-Pack 3-way, X-124 Blower Speed Input

1шт.

23

87692880

CABLE TERMINAL

Weather-Pack I Male

2шт.

24

87644909

WIRE CONNECTOR,Female, 3 Pins

Weather-Pack 3-way, X-125 HVAC Temperature Control

1шт.

24

87692880

CABLE TERMINAL

Weather-Pack I Male

1шт.

24

87692882

ELEC. TERMINAL PIN

Weather-Pack Male

1шт.

25

382391A1

MULTIPOLE CONNECTOR,Female, 10 Pin

10-way, X-287A Manual Switch

1шт.

25

87697756

TERMINAL

Metri-Pack .630 Female

3шт.

26

87688695

ELEC CONNECTOR,Female, 1 Cavity

56 Series 1-way, X-268B Low Beam

1шт.

27

113699A1

RECTIFIER

Inline, 12V 1A

1шт.

28

87693717

ELEC CONNECTOR

56 Series 1-way, X-268A Low Beam

1шт.

28

225114C1

CONTACT

56 Series Male

1шт.

29

87426882

CONNECTOR, ELEC

10-way, X-129 Strobe/Beacon Switch

1шт.

29

87697756

TERMINAL

Metri-Pack .630 Female

2шт.

29

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Metri-Pack .630

1шт.

30

87426886

CONNECTOR, ELEC

10-way, X-245 EHR/EDC Switch

1шт.

30

87697756

TERMINAL

Metri-Pack .630 Female

5шт.

30

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Metri-Pack .630

1шт.

31

87426892

CONNECTOR, ELEC

10-way, X-316 Hazard Switch

1шт.

31

87697756

TERMINAL

Metri-Pack .630 Female

2шт.

31

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Metri-Pack .630

2шт.

32

87426886

CONNECTOR, ELEC

10-way, X-244 Auto Hitch Switch, X-424 Diode Block

1шт.

32

87697756

TERMINAL

Metri-Pack .630 Female

2шт.

33

227393A1

CONNECTOR, ELEC

Metri-Pack .280 6-way, X-178 Intermittent Front Wiper Switch

1шт.

33

87693338

CONTACT

Metri-Pack .280

5шт.

33

87693337

TERMINAL CONNECTOR

Metri-Pack .280

1шт.

33

87705076

RETAINER

Blue Secondary Lock, 6-way

1шт.

34

87426892

CONNECTOR, ELEC

10-way, X-3000 Aux Headlamp Switch

1шт.

34

87697756

TERMINAL

Metri-Pack .630 Female

5шт.

34

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Metri-Pack .630

1шт.

Выбрано товаров: 83
