Запчасти Case IH MAGNUM 260 (90.100.AU[01]) - HOOD, FIXED (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

84170648

BRACKET, SUPPORTING

1шт.

2

833-41308

SPRING NUT,M8, U

Multi-Thread Long

4шт.

3

86639316

WASHER,8.4mm ID x 20mm OD x 2mm Thk

8.4 x 20 x 2mm CST BZN

6шт.

4

87705500

BRACKET, SUPPORTING

2шт.

5

84324316

PANEL

RH, Wheel Well

1шт.

6

84324315

PANEL

LH, Wheel Well

1шт.

7

825-2408

FLANGE NUT,M8 x 1.25, Flg, Cl 8

2шт.

8

844-8020

BOLT,Hvy Hex, M8 x 20mm, Cl 8.8

10шт.

9

84357268

MOUNT

1шт.

10

87698746

BOLT,Hex, M16 x 45mm, Cl 10.9

Flange M16 x 45 Full 10.9 ZND

3шт.

11

301081A1

BOLT

Striker

1шт.

12

84353753

BRACKET

Assy Mounting

1шт.

13

87698836

BOLT,M10 x 25mm, Full Thd, Cl 10.9

Flange M10 x 25 Full 10.9 ZND

2шт.

14

84493582

BRACKET, SUPPORTING

Deaeration and Stiffner Assy

1шт.

15

844-8030

BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8

2шт.

16

84403414

STRIP

Plastic Hood Guide

1шт.

17

844-6020

BOLT,Hvy Hex, M6 x 20mm, Cl 8.8

2шт.

18

825-5146

SERRATED NUT,M6, Flg Ser

2шт.

19

84402324

NUT

Crown, M8 - 1.25

9шт.

20

86705425

BOLT,Hvy Hex, M8 x 80mm, Cl 8.8

1шт.

21

84258795

STUD

Threaded

1шт.

22

627-16060

BOLT,Hex, M16 x 2 x 60mm, Cl 10.9, Full Thd

4шт.

23

896-11016

WASHER,17.5mm ID x 30mm OD x 4mm Thk

5шт.

24

825-2416

FLANGE NUT,M16 x 2, Flg, Cl 8

1шт.

25

84402324

NUT

Crown

2шт.
