Запчасти Case IH MAGNUM 255 (09-23) - CAB - TRIM, FENDERS (09) - CHASSIS/ATTACHMENTS

1

426575A1

TRIM PANEL

Left Hand, Inc. 41

1шт.

Without CD Player

1шт.

1

426576A1

TRIM PANEL

Left Hand, Inc. 41

1шт.

With CD Player

1шт.

2

87417629

TRIM PANEL

1шт.

3

358805A1

HOLDER

1шт.

4

301901A1

INSERT

1шт.

5

93199C1

FASTENER

15шт.

6

360362A1

CAPTIVE WASHER SCREW

No. 10 x 1

4шт.

8

358806A1

COVER

1шт.

10

87444946

TRIM PANEL

Right Hand

1шт.

12

278316A2

CLIP

6шт.

13

87451321

PANEL

1шт.

Without Auto Temp Control

1шт.

13

87451319

PANEL

1шт.

With Auto Temp Control

1шт.

17

302456A1

ASH TRAY

1шт.

19

426580A1

TRIM PANEL

Rear

1шт.

19

87313020

TRIM PANEL

Auto Guidance

1шт.

20

357169A2

TRIM PANEL

Left Hand, Serial Range: -Z7RZ01382

1шт.

20

87309897

TRIM PANEL

Left Hand, Start Serial: Z7RZ01382

1шт.

21

357168A2

TRIM PANEL

Right Hand, Serial Range: -Z7RZ01382

1шт.

21

87309901

TRIM PANEL

Right Hand, Start Serial: Z7RZ01382

1шт.

22

93199C1

FASTENER

2шт.

23

360362A1

CAPTIVE WASHER SCREW

No. 10 x 1

2шт.

24

87309745

STUD

, Start Serial: Z7RZ01382

2шт.

25

322413A2

STUD

, Start Serial: Z7RZ01382

2шт.

27

359037A1

HOOK

4шт.

28

322413A2

STUD

, Serial Range: -Z7RZ01382

4шт.

29

359036A1

NET,Cargo

1шт.

30

358807A1

SILL

1шт.

31

360362A1

CAPTIVE WASHER SCREW

No. 10 x 1

2шт.

32

87016569

SPRING NUT,U, #10-16, Panel type

10шт.

33

358682A1

GUARD

1шт.

34

451984A1

PUSH-ON NUT

3шт.

35

280628A1

PLUG

1шт.

Without Power Mirrors

1шт.

37

322072A2

FASTENER

2шт.

38

322073A1

NUT

2шт.

39

336383A1

PAD

1шт.

40

336385A1

PAD

1шт.

41

360365A1

DIFFUSER

1шт.

42

151-537

RIVET,Pop, 1/8" x .650"

4шт.

43

895-11003

WASHER,3.2mm ID x 7mm OD x 0.5mm Thk

4шт.

44

104033C2

SELF-TAP SCREW,Truss HD, #10 - 16 x 3/4"

2шт.

50

355101A2

BOX

1шт.

With CD Player

1шт.

51

355102A2

DOOR

1шт.

With CD Player

1шт.

52

364279A1

PLATE

2шт.

With CD Player

1шт.

53

364281A1

CATCH

2шт.

With CD Player

1шт.

54

260-16516

SELF-TAP SCREW,Cross Pan Hd, #10 x 1"

4шт.

With CD Player

1шт.

56

87679383

BRACKET

Bracket

1шт.

57

825-2408

FLANGE NUT,M8 x 1.25, Flg, Cl 8

7шт.

58

353-411

PLUG,Dome, 1.000" hole, Nylon

1шт.

59

86984858

FOAM

1шт.

60

405011A3

BRACKET

1шт.

61

428192A2

BEZEL

1шт.

62

760-17113

SELF-TAP SCREW,Pan Hd, M3.5 x 13

8шт.

63

760-17316

SELF-TAP SCREW,Pan Hd, M4.2 x 16

1шт.

64

376597A2

DECAL

(Not Shown)

1шт.

65

87421503

FOAM

Left Hand Fender Trim Support

1шт.

66

87313017

FOAM

Auto Guidance

2шт.

67

353-422

PLUG,Dome, 1.250" hole, Nylon

(Not Shown)

1шт.

For Harness Hole In Box

1шт.
