Запчасти Case IH MAGNUM 235 (33.220.AC[01]) - BRAKES, HYDRAULIC SYSTEM, WITHOUT TRAILER BRAKES (33) - BRAKES & CONTROLS

1

87731065

BRAKE VALVE

1шт.

2

700-106

HYD CONNECTOR,11/16" - 16 Male ORFS x M18 x 1.5 Male ORB

2шт.

3

316443A2

FITTING

Incl 17 - 20

1шт.

4

L11541

CABLE TIE,203.2mm L, Nylon

1шт.

5

87731873

HOSE,9.53mm ID x 704mm L

1шт.

6

238-6012

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

3шт.

7

87577426

HYDRAULIC HOSE,12.70 mm ID x 1080.00 mm, SAE 100R6

1шт.

8

87454069

ELBOW,90 Degree Hose Barb, 1/2" ID x M18 x 1.5 Male ORB

1шт.

9

700-102

HYD CONNECTOR,13/16" - 16 Male ORFS x M18 x 1.5 Male ORB

Incl 21, 26, 27

2шт.

10

214-1408

HOSE CLAMP,11.2mm - 19.8mm

2шт.

11

1546024C1

CLAMP

3шт.

12

829-1408

NUT,Hex, M8 x 1.25, Cl 10.9

4шт.

13

384870A1

PLATE

3шт.

14

84151503

RIGID TUBE

1шт.

15

84150573

RIGID TUBE

1шт.

16

433588A1

TUBE

1шт.

17

NSS

NOT SOLD SEPARAT

Fitting, Incl in 3

1шт.

18

637-63153

O-RING,2.2mm Thk x 15.3mm ID, Cl 6, 90 Duro

1шт.

19

238-6014

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

1шт.

20

326965A1

FILTER STRAINER,10.46mm OD x 33.7mm L, 140 Micron

1шт.

21

70923841

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

1шт.

22

87331123

FITTING

Incl 23

1шт.

23

237-6008

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

1шт.

24

87625539

HYDRAULIC HOSE

2шт.

25

84160886

HYDRAULIC HOSE,9.53mm ID x 675mm L

Fitting, Incl in 9

2шт.

26

NSS

NOT SOLD SEPARAT

1шт.

27

14437985

O-RING,15.3mm ID x 2.4mm

1шт.
