Запчасти Case IH MAGNUM 225 (44.100.02) - HUB ASSEMBLY, REAR WHEELS WITH KEYED SHAFT (44) - WHEELS

1

719677006

DIA KIT, TRACTOR

Dual Wheel Hub Assembly, Inc. 2 - 12

1шт.

2

827-22080

BOLT,Hex, M22 x 2.5 x 80mm, Cl 10.9

20шт.

3

896-11022

WASHER,24mm ID x 44mm OD x 4mm Thk

20шт.

6

405812A1

HUB

2шт.

7

405815A1

BUSHING

102 mm (4 in)

2шт.

8

228273A1

BOLT,Hex, M20 x 2.5 x 110mm, Cl 10.9

12шт.

9

396-31081

WASHER,20.63mm ID x 38.1mm OD x 5.56mm Thk

12шт.

10

A63219

KEY

3/4 x 6

2шт.

11

38-11608

LOCK PIN,1/4" x 1/2", Slotted

2шт.

12

303401A1

PLUG

6шт.
