Запчасти Case IH MAGNUM 190 (55.785.03) - KIT, MONITOR MOUNTING (55) - ELECTRICAL SYSTEMS

1

84372055

KIT

Inc. 2 - 15

1шт.

2

86625256

WASHER,13.3mm ID x 28.5mm OD x 4mm Thk

1шт.

3

82039389

CUP WASHER,12.5mm ID x 50mm OD x 17mm Thk, Glass Filled Nylon

1шт.

4

87583911

BASE PLATE

1шт.

5

82038414

HALF BALL

1шт.

6

87568603

SPECIAL BOLT,Hex, M12 x 60

1шт.

7

87353504

KNOB

1шт.

8

120162

HEX SOC SCREW,M6 x 35mm, Cl 8.8

1шт.

9

89832203

SCREW

2шт.

10

86624182

WASHER,6.6mm ID x 18mm OD x 1.6mm Thk

3шт.

11

12601279

WAVE WASHER,6.40mm ID x 12mm OD x 0.50mm, 2.60mm H, STL, ZND

3шт.

12

9706755

NUT,M6, Cl 8

3шт.

13

14305221

HEX SOC SCREW,M6 x 16mm, Full Thd, Cl 8.8

4шт.

14

84369437

MOUNT

1шт.

15

84228344

HARNESS

SWCD (Not Shown)

1шт.
