Запчасти Case IH MAGNUM 190 (55.100.02[01]) - HARNESS, CHASSIS, WITH POWERSHIFT TRANSMISSION (55) - ELECTRICAL SYSTEMS

1

84372470

HARNESS

Chassis, Incl 2 - 26, 83 - 91, Serial Range: -ZCRH01025

1шт.

1

84481524

HARNESS

Chassis, Incl 2 - 26, 84 - 89, 91, Start Serial: ZCRH01026

1шт.

2

82016219

MULTIPOLE CONNECTOR,Female, 26 Pole

UCM, 92

1шт.

3

82028495

MULTIPOLE CONNECTOR,Female, 34 Pole

UCM, 93

1шт.

4

82028493

MULTIPOLE CONNECTOR,Female, 26 Pole

UCM, 91

1шт.

5

82028495

MULTIPOLE CONNECTOR,Female, 34 Pole

UCM, 99

1шт.

6

84130757

ELEC CONNECTOR,Female, 26 Cavities

UCM, 94

1шт.

7

84130760

ELEC CONNECTOR,Female, 34 Cavities

UCM, 95

1шт.

8

280451A1

CONNECTOR,ELECTRIC

Cavity Plug

1шт.

9

280453A1

ELEC CONNECTOR,Male, 6 Pin

Calibration, 601M

1шт.

10

87382927

ELEC CONNECTOR,Male, 14 Cavities

ISO, 294F

1шт.

11

87382926

WIRE CONNECTOR,Female, 14 Cavities

Cavity Plug

1шт.

12

297910A1

ELEC CONNECTOR,Female, 5 Pin

Relay 1, 2, 3, 5 Pin

3шт.

13

87699386

MULTIPOLE CONNECTOR,Female, 24 Pole

EPL, 700

1шт.

14

87695723

ELEC CONNECTOR,Male , 3 Pole

Left Fender Hitch Control, 314F

1шт.

15

87382921

WIRE CONNECTOR,Male

396M, 6 Pin

1шт.

16

182064A1

CONNECTOR, ELEC

40F, 1 Pin

1шт.

17

87382919

WIRE CONNECTOR,Male, 6 Cavities

21M

1шт.

18

82028495

MULTIPOLE CONNECTOR,Female, 34 Pole

UCM, 100

1шт.

19

338056A1

FUSE,40A, Maxival, Orange

4358

1шт.

20

82028493

MULTIPOLE CONNECTOR,Female, 26 Pole

UCM, 97

1шт.

21

87382918

WIRE CONNECTOR,Female, 6 Cavities

397F

1шт.

22

225351C1

ELEC CONNECTOR,Female, 6 Pin

20M

1шт.

23

182064A1

CONNECTOR, ELEC

41F, 1 Pin

1шт.

24

87695723

ELEC CONNECTOR,Male , 3 Pole

Right Fender Hitch Control, 315F

1шт.

25

NSS

NOT SOLD SEPARAT

ISO Can, 706, 2 Pin

1шт.

26

437552A1

ELEC CONNECTOR,Female, 102 Pin

To Cab Harness, 10M

1шт.

83

84189831

HARNESS

High Flow Pump, Serial Range: -ZCRH01025

1шт.

84

87527952

BRACKET

1шт.

85

515-23412

CLAMP,1 5/8", Insul, 3/8" Bolt

3шт.

86

87495305

CLAMP,65mm, Coat, 8.7mm Bolt Hole, P Type

2шт.

87

86511841

BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8

2шт.

88

9804277

FLANGE NUT,Hex, M8 x 1.25, Cl 8

3шт.

89

86625263

WASHER,9mm ID x 20mm OD x 1.6mm Thk

1шт.

90

16323321

BOLT,Hex Lock, M10 x 1.25 x 20.00mm, 8R, ZND

, Serial Range: -ZCRH01025

1шт.

91

293256A2

RELAY,12V

3шт.
