1
230135A1
SHAFT
ASSEMBLY - output, no longer available, order 230135A2 shaft below
1шт.
1
230135A2
SHAFT
ASSEMBLY - output, Includes: Ref. 2-5
1шт.
2
1342852C1
PLUG
sealing, 12 mm, used with 230135A1 shaft assembly
3шт.
2
187516A1
PLUG,Expansion, 12mm
expansion, used with 230135A2 shaft assembly
3шт.
4
38-3605
PIN,3/32" x 5/16", Coiled
6шт.
5
1963875C1
COTTER PIN
slotted spring
4шт.
8
1286040C2
SEAL,63.6mm ID x 69.8mm OD x 6.5mm Thk
support
1шт.
9
1997888C1
THRUST WASHER,70.25mm ID x 95mm OD x 3.13mm Thk
1шт.
10
1286016C1
NEEDLE BEARING,Needle, 63.49mm ID x 73.05mm OD x 31.75mm W
caged
1шт.
11
1285985C1
GEAR
odd/even clutch and fifth, 34 teeth
1шт.
12
1285987C1
PINION
GEAR - driven, reverse, 39 teeth
1шт.
13
1286052C1
RING,Locking, 98.8mm ID x 106.6mm OD x 4.5mm Thk
seal
2шт.
16
1286043C1
THRUST WASHER,63.56mm ID x 82.38mm OD x 2.37mm Thk
4шт.
17
572182R1
THRUST BEARING,63.5mm ID x 82.5mm OD x 1.98mm W
needle
2шт.
18
93350C1
RING
retaining
4шт.
19
1286012C2
BELLEVILLE WASHER
Belleville spring
24шт.
20
93304C2
CLUTCH HOUSING
CARRIER -
1шт.
22
1286081C1
O-RING,1.78mm Thk x 69.57mm ID, -39, 60 Duro
piston, low clutch inner
2шт.
23
1286076C1
RING,73.46mm ID x 76.5mm OD x 2.28mm Thk
piston, clutch
2шт.
24
1285998C1
PISTON
clutch
2шт.
25
1286083C1
O-RING,1.78mm Thk x 120.37mm ID, -48, 60 Duro
piston, low clutch outer
2шт.
26
1286079C1
RING,128.96mm ID x 132mm OD x 2.28mm Thk
piston, shift
2шт.
29
93129C1
BELLEVILLE WASHER
Belleville spring
3шт.
30
93190C1
CLUTCH PLATE,107mm ID x 158mm OD x 2.01mm Thk
reaction
2шт.
31
92935C5
DISC,98.63mm ID x 141mm OD x 1.95mm Thk
friction
14шт.
32
92934C2
DISC
separator
12шт.
33
1342854C2
DISC
backing, 16.5 mm (21/32 inch) thick, if used
2шт.
33
1342645C3
CLUTCH DISC
CLUTCH DISK backing, powder coated, 9.7 mm (3/8 inch) thick, if used
2шт.
34
1285996C1
SNAP RING,151mm OD, Internal
retaining
2шт.
35
93129C1
BELLEVILLE WASHER
Belleville spring
3шт.
36
80907C1
NEEDLE BEARING,Needle, 57.15mm ID x 66.7mm OD x 25.4mm W
caged
1шт.
37
1342513C1
SPACER
bearing
1шт.
39
1286042C1
THRUST WASHER,57.21mm ID x 76.05mm OD x 2.37mm Thk
2шт.
40
K620185
THRUST BEARING
needle, thrust
1шт.
44
219530H1
BEARING ASSY,49.99mm ID x 24.71mm W
tapered roller
1шт.
45
ST964
BEARING CUP,2.063" ID x 3.626" OD x 0.9768"
tapered roller
1шт.
46
1286024C1
SEALING RING,Locking, 46.61mm ID x 50.61mm OD x 2.87mm Thk
seal
4шт.
47
238-5223
O-RING,0.139" Thk x 1.609" ID, -223, Cl 5, 75 Duro
1-3/4 ID x 1/8 inch wide
1шт.
