Артикул
Название
Примечание
Количество
1
1999922C1
HOSE
1650 mm (65 inch) long, suction, compressor to cab base, R12 refrigerant applications only, no longer available, order 1999922C2 hose below, Includes: Ref. 2 thru 4
1шт.
1
1999922C2
HOSE
1650 mm (65 inch) long, suction, compressor to cab base, 134A and R12 refrigerant applications, Includes: Ref. 2 thru 4
1шт.
3
1250594C1
CORE
VALVE - core
1шт.
5
232948A1
SWITCH, A/C HIGH PRE
400 psi, Replaces 375 psi switch used on some models
1шт.
6
181583A1
CONDENSER
air conditioning, see Figure 5-018 for hardware attaching condenser to oil cooler, see Figure 3-020 or 3-024 for fuel cooler lines
1шт.
7
192929A2
HOSE
413 mm (16-17/64 inch) long, condenser to receiver-drier, Includes: Ref. 8
1шт.
9
223357A1
FIXING BRACKET
CLAMP - retaining
1шт.
14
1954490C2
CLAMP
retaining
1шт.
15
413-816
BOLT,Hex, 1/2" - 13 x 1", Gr 5
1шт.
16
80679
LOCK WASHER,1/20.507 CST ZND
1шт.
17
425-108
NUT,1/2" - 13, Gr 5
1шт.
18
1954766C2
CLAMP
retaining
1шт.
19
762-24613
SELF-TAP SCREW,Flat Hd, M6 x 13
Special
2шт.
30
1990758C2
RECEIVER-DRYER
air conditioning
1шт.
31
T102980
CLAMP
BRACKET - receiver-drier mounting
1шт.
33
276-14832
SELF-TAP SCREW,Hex Hd, 5/16" x 2"
1шт.
35
131249A1
A/C HOSE
2800 mm (110-1/4 inch) long, receiver-drier to cab, Includes: Ref. 36
1шт.
37
L18337
CABLE TIE,9.95"-12.1" lg
CABLE STRAP tie, 15 inch
1шт.
41
186468A2
HOSE
1500 mm (59-1/16 inch) long, discharge, compressor to condenser, R12 refrigerant applications only, see 186468A3 hose below, Includes: Ref. 42 thru 46
1шт.
41
186468A3
HOSE
1500 mm (59-1/16 inch) long, discharge, compressor to condenser, 134A and R12 refrigerant applications, Includes: Ref. 42 thru 46
1шт.
42
128484A1
O-RING,0.07" Thk x 0.426" ID, -13, Cl 5, 70 Duro
7/16 ID x 1/16 inch wide, at condenser
1шт.
43
O-RING,1.78mm Thk x 7.65mm ID, 70 Duro
5/16 ID x 1/16 inch wide, at pressure switch fitting
1шт.
45
122554A1
CAP
Sealing, charge port
1шт.
47
234017A1
HEX SOC SCREW
BOLT - hex socket, 8 - 1.25 x 16 mm, mounts hoses to radiator, Replaces: P/N 844-8016 bolt
2шт.
Выбрано товаров: 30
