1
J924422
COVER ASSY
COVER gear, front, Replaces: P/N J916192 cover
1шт.
2
NSS
NOT SOLD SEPARAT
SEAL oil, crankshaft front, order Ref. 26, P/N A77790 kit below
1шт.
3
J917779
GASKET,0.98mm Thk
front cover, Replaces: P/N J913429 gasket
1шт.
4
J917316
MOTOR HOUSING
HOUSING timing gear, Replaces: P/N J915073 housing
1шт.
5
J281721
GASKET
gear housing, Replaces: P/N J914303 gasket
1шт.
6
845-8050
BOLT,Hvy Hex, M8 x 50mm, Cl 8.8
heavy hex flange, 8 - 1.25 x 50 mm
6шт.
7
845-8016
BOLT,Hvy Hex, M8 x 16mm, Cl 8.8
- heavy hex flange, 8 mm-1.25 x 16 mm
17шт.
8
845-8020
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
- heavy hex flange, 8 - 1.25 x 20 mm
5шт.
9
854-12050
BOLT,Hvy Hex, M12 x 50mm, Cl 10.9
4шт.
10
J900257
PIN,10.01mm OD x 16mm L
dowel, locating, 16 mm
2шт.
11
J906619
PLUG,1/8" - 27
hex, 1/8 inch PT
3шт.
12
J903475
SEALING RING,72.39mm ID x 90.39mm OD x 9mm Thk
cover
1шт.
13
J909918
PLATE
accessory drive cover, no longer available, for service Order: P/N J914868 plate, Ref. 14
1шт.
14
J914868
COVER
PLATE accessory drive cover
1шт.
15
J913288
SEAL
GASKET cover plate, no longer available, for service Order: P/N J919601 gasket, Ref. 16
1шт.
16
J919601
GASKET
cover plate
1шт.
17
854-12025
BOLT,Hvy Hex, M12 x 25mm, Cl 10.9
heavy hex flange, 12 - 1.75 x 25 mm, class 10.9
2шт.
18
J919683
HOUSING
timing pin, Replaces: P/N J905933 housing
1шт.
19
J915772
SEAL,Square, 1.68mm Thk x 29.87mm ID, -25
SEALRING quad, timing pin housing, Replaces: P/N J914092 ring
1шт.
20
J907998
SCREW,M5 x 0.8 x 17mm, Cl 8.8
LOCK, Spc Rd Torx Hd, M5 x 17
2шт.
21
J903924
PIN,18.87mm OD x 55mm L
timing
1шт.
22
J913994
O-RING
sealing, timing pin
1шт.
23
J904849
SNAP RING,0.875", Int, #87
RING, SNAP, , timing pin 0.875", Int, #87
1шт.
24
J903463
PLUG,M63 x 5
front access
1шт.
25
A77552
PLUG
expansion, 29/64 inch diameter
1шт.
26
A77790
SEAL KIT
KIT seal, crankshaft front, Includes: Ref. 27-30
1шт.
27
NSS
NOT SOLD SEPARAT
SEAL oil, front
1шт.
28
NSS
NOT SOLD SEPARAT
TOOL installation
1шт.
29
NSS
NOT SOLD SEPARAT
TOOL installation
1шт.
30
J918113
SHIELD,74.73mm ID x 91.7mm OD x 6mm Thk
dust, crank seal
1шт.
