Артикул
Название
Примечание
Количество
1
1542599C1
COVER
- end, outlet, with plugs, no longer available, order 1978363C2 cover, 218-5209 plug and 218-5212 plug, Replaces: 1978363C1, Includes: Ref. 2 - 5
1шт.
2
218-5158
PLUG,Hex Hd, 1 1/16"-12 ORB
- hex, 1-1/16-12 inch O-ring boss, if used
1шт.
2a
9841223
PLUG,1-1/16" - 12 ORB
If used, Not shown, Incl. Ref. 3 Hex Soc, 1 1/16"-12 ORB
1шт.
3
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
12-1, 90 Duro, .924 ID x .116" Thk
1шт.
4
9625178
PLUG,9/16" - 18 ORB
Incl. Ref. 5 Hex Soc, 9/16"-18 ORB
1шт.
6
REF
INSTRUCTION
VALVE ASSEMBLY - remote, first remote with load check, 20 gallon, See Figures 8-62 - 8-64
1шт.
7
REF
INSTRUCTION
VALVE ASSEMBLY - remote, second, third and fourth remote with load check, 30 gallons, See Figures 8-66 - 8-68
1шт.
8
238-6117
O-RING,0.103" Thk x 0.799" ID, -117, Cl 6, 90 Duro
(Replaces P/N D63414) -117, 90 Duro, .799" ID x .103" Thk
10шт.
9
O-RING,0.103" Thk x 0.487" ID, -112, Cl 6, 90 Duro
(Replaces P/N H756783) -112, 90 Duro, .487" ID x .103" Thk
3шт.
10
1334558C1
STUD
- valve, 12 x 210 mm, class 10.9, if used
2шт.
10
1994612C1
STUD
- valve, 12 x 225 mm, if used
2шт.
11
1334557C2
STUD
- valve, 10 x 225 mm, class 10.9, Replaces: 1334557C1
1шт.
14
829-1312
NUT,M12 x 1.75, Cl 10
- hex, 12 mm - 1.75, class 10, Replaces 30169R1
2шт.
15
829-1310
NUT,M10, Cl 10
Replaces 30168R1 M10, Cl 10
1шт.
16
1346059C2
SHIM
- auxiliary valve stack, if equipped
1шт.
18
218-5158
PLUG,Hex Hd, 1 1/16"-12 ORB
ASSEMBLY - hex, 1-1/16 inch thread, used without auxiliary hydraulic motor, Includes: Ref. 19
1шт.
19
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
- 15/16 x 1-5/32 x 7/64 inch
1шт.
20
1978363C2
COVER
- end, outlet, without plugs
1шт.
21
218-5158
PLUG,Hex Hd, 1 1/16"-12 ORB
- hex, 1-1/16-12 inch O-ring boss, if used
1шт.
21a
9841223
PLUG,1-1/16" - 12 ORB
If used, Not shown, Incl. Ref. 22 Hex Soc, 1 1/16"-12 ORB
1шт.
22
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
12-1, 90 Duro, .924 ID x .116" Thk
1шт.
23
9625178
PLUG,9/16" - 18 ORB
Incl. Ref. 24 Hex Soc, 9/16"-18 ORB
1шт.
5
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
6-1, 90 Duro, .468" ID x .078" Thk, Boss end
1шт.
24
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
6-1, 90 Duro, .468" ID x .078" Thk, Boss end
1шт.
Выбрано товаров: 24
