Запчасти Case IH SO-SERIES (089) - REAR WHEEL FENDERS, FOR SO TRACTOR (06) - POWER TRAIN

5472A

SUPPORT, fender. Use A5472A

1шт.

A5472A

SUPPORT, fender

2шт.

O4709AB

STRAP, fender support. Use O6577AB

2шт.

O6577AB

BOLT, "U" fender support

2шт.

NUT, 5/8" hexagon, N.C. thread

4шт.

WASHER, 5/8" standard lock

4шт.

2652AA

FENDER, R.H.

1шт.

SCREW, 7/16" x 1-3/4" hexagon head cap, N.F. thread

4шт.

NUT, 7/16" hexagon, light, N.F. thread

4шт.

WASHER, 7/16" standard lock

4шт.

SCREW, 5/16" x 1" truss head machine, N.C. thread, with hexagon nut

2шт.

WASHER, 5/16" plain

2шт.

WASHER, 5/16" standard lock

2шт.

2653AA

FENDER, L.H.

1шт.

SCREW, 7/16" x 1-3/4" hexagon cap, N.F. thread

4шт.

NUT, 7/16" hexagon, light, N.F. thread

4шт.

WASHER, 7/16" standard lock

4шт.

SCREW, 5/16" x 1" truss head machine, N.C. thread, with hexagon nut

2шт.

WASHER, 5/16" plain

2шт.

WASHER, 5/16" standard lock

2шт.

O6639A

SPRING, battery service door catch, orchard side fenders and crowl for "SO" Tractor

1шт.

O6442AB

SHEET, front extension, R.H. fender. Prior to tractor No. 4900000. See O7986AB, orchard side fenders and crowl for "SO" Tractor

1шт.

SCREW, 1/4" x 3/4" truss head machine, N.C. thread, with hexagon nut, orchard side fenders and crowl for "SO" Tractor

4шт.

WASHER, 1/4" standard lock, orchard side fenders and crowl for "SO" Tractor

4шт.

O6444AB

BRACKET, fender extension front. Prior to tractor No. 4900000 and after tractor No. 5300001. See O7988AB, orchard side fenders and crowl for "SO" Tractor

2шт.

SCREW, 3/8" x 1-1/4" hexagon head cap, N.F. thread, orchard side fenders and crowl for "SO" Tractor

2шт.

NUT, 3/8" hexagon, light, N.F. thread, orchard side fenders and crowl for "SO" Tractor

2шт.

WASHER, 3/8" standard lock, orchard side fenders and crowl for "SO" Tractor

2шт.

O6445AB

BRACKET, fender extension rear, orchard side fenders and crowl for "SO" Tractor

2шт.

O6447AB

BRACE, fender extension, orchard side fenders and crowl for "SO" Tractor

2шт.

NUT, 5/8" hexagon, light, N.F. thread, orchard side fenders and crowl for "SO" Tractor

4шт.

O6448AB

BRACKET, fender extension brace. Prior to tractor No. 4900000. See O7982AB, orchard side fenders and crowl for "SO" Tractor

2шт.

SCREW, 1/2" x 1-1/4" hexagon cap, N.C. thread

2шт.

WASHER, 1/2" standard lock, orchard side fenders and crowl for "SO" Tractor

2шт.

O6449AB

COVER, fender extension hand hole, orchard side fenders and crowl for "SO" Tractor

2шт.

SCREW, 1/4" x 1/2" truss head machine, N.C. thread, with hexagon nut, orchard side fenders and crowl for "SO" Tractor

8шт.

WASHER, 1/4" standard lock, orchard side fenders and crowl for "SO" Tractor

8шт.

O6451AB

CATCH, battery service door, orchard side fenders and crowl for "SO" Tractor

1шт.

O6452AB

PIN, battery service door catch, orchard side fenders and crowl for "SO" Tractor

1шт.

PIN, 3/32" x 5/8" cotter, orchard side fenders and crowl for "SO" Tractor

1шт.

WASHER, 1/4" plain, orchard side fenders and crowl for "SO" Tractor

1шт.

O6453AB1

BRACKET, air cleaner fender extension sheet, orchard side fenders and crowl for "SO" Tractor

1шт.

SCREW, 3/8" x 3/4" hexagon head cap, N.F. thread

1шт.

O6454AB

SUPPORT, fender extension front, R.H., orchard side fenders and crowl for "SO" Tractor

1шт.

O6455AB

SUPPORT, fender extension front, L.H., orchard side fenders and crowl for "SO" Tractor

1шт.

O6458AB

SUPPORT, cowl, R.H. Prior to tractor No. 4900000. See O7978AB, orchard side fenders and crowl for "SO" Tractor

1шт.

O6459AB

SUPPORT, cowl, L.H. Prior to tractor No. 4900000. See O7978AB, orchard side fenders and crowl for "SO" Tractor

1шт.

O7978AB

ROD, cowl tension. Tractor No. 4900000 and after. See O6458AB - O6459AB, orchard side fenders and crowl for "SO" Tractor

2шт.

NUT, 5/16" hexagon, light, N.F. thread, orchard side fenders and crowl for "SO" Tractor

2шт.

O7979AB

BRACKET, cowl tension rod. Tractor No. 4900000 and after, orchard side fenders and crowl for "SO" Tractor

2шт.

O7982AB

BRACKET, fender extension brace. Tractor No. 4900000 and after. See O6448AB, orchard side fenders and crowl for "SO" Tractor

2шт.

SCREW, 1/2" x 1-1/4" hexagon head cap, N.C. thread, orchard side fenders and crowl for "SO" Tractor

2шт.

WASHER, 1/2" standard lock, orchard side fenders and crowl for "SO" Tractor

2шт.

O7983AB

SHIM, fender. Tractor No. 4900000 and after, orchard side fenders and crowl for "SO" Tractor

2шт.

O7984AB

ANTI-SQUEAK, cowl. Tractor No. 4900000 and after, orchard side fenders and crowl for "SO" Tractor

1шт.

O7985AB

BRACKET, fender extension attaching. Tractor No. 4900000 to No. 5300000, orchard side fenders and crowl for "SO" Tractor

2шт.

O7986AB

SHEET, front extension, R.H. fender. Tractor No. 4900000 and after. See O6442AB, orchard side fenders and crowl for "SO" Tractor

1шт.

BOLT, 3/8" x 1-1/4" carriage, with hexagon nut, orchard side fenders and crowl for "SO" Tractor

1шт.

SCREW, 1/4" x 3/4" truss head machine, N.C. thread, with hexagon nut, orchard side fenders and crowl for "SO" Tractor

4шт.

WASHER, 1/4" standard lock, orchard side fenders and crowl for "SO" Tractor

4шт.

WASHER, 3/8" standard lock, orchard side fenders and crowl for "SO" Tractor

1шт.

O7988AB

BRACKET, fender extension front sheet. Tractor No. 4900000 to No. 5300000, orchard side fenders and crowl for "SO" Tractor

2шт.

SCREW, 3/8" x 1-1/4" hexatgon head cap, N.F. thread, orchard side fenders and crowl for "SO" Tractor

2шт.

NUT, 3/8" hexagon, light, N.F. thread, orchard side fenders and crowl for "SO" Tractor

2шт.

WASHER, 3/8" standard lock, orchard side fenders and crowl for "SO" Tractor

2шт.

2643AA

SHEET, front extension, L.H. fender, with battery service door. Prior to tractor No. 4900000, orchard side fenders and crowl for "SO" Tractor

1шт.

SCREW, 1/4" x 1/2" oval head steel machine, N.C. thread, orchard side fenders and crowl for "SO" Tractor

1шт.

SCREW, 1/4" x 3/4" oval head steel machine, N.C. thread, orchard side fenders and crowl for "SO" Tractor

4шт.

NUT, 1/4" hexagon, N.C. thread, orchard side fenders and crowl for "SO" Tractor

5шт.

WASHER, 1/4" standard lock, orchard side fenders and crowl for "SO" Tractor

5шт.

A2643AA

SHEET, front extension, L.H. fender, with battery service door. Tracto No. 4900000 and after, orchard side fenders and crowl for "SO" Tractor

1шт.

BOLT, 3/8" x 1-1/4" carriage, with hex nut, orchard side fenders and crowl for "SO" Tractor

1шт.

SCREW, 1/4" x 1/2" truss head machine, N.C. thread, with hexagon nut, orchard side fenders and crowl for "SO" Tractor

1шт.

SCREW, 1/4" x 3/4" truss head machine, N.C. thread, with hexagon nut, orchard side fenders and crowl for "SO" Tractor

4шт.

WASHER, 1/4" standard lock, orchard side fenders and crowl for "SO" Tractor

5шт.

WASHER, 3/8" standard lock, orchard side fenders and crowl for "SO" Tractor

1шт.

2649AA

COWL AND REINFORCEMENT ROD, orchard side fenders and crowl for "SO" Tractor

1шт.

SCREW, 1/4" x 1/2" truss head machine, N.C. thread, with hexagon nut, orchard side fenders and crowl for "SO" Tractor

6шт.

SCREW, 1/4" x 3/4" truss head machine, N.C. thread, with hexagon nut, orchard side fenders and crowl for "SO" Tractor

6шт.

WASHER, 1/4" standard lock, orchard side fenders and crowl for "SO" Tractor

12шт.

2654AA

SHEET, outer extension, R.H. fender. Prior to tractor No. 4900000, orchard side fenders and crowl for "SO" Tractor

1шт.

BOLT, 1/2" x 2" carriage, with hex nut, orchard side fenders and crowl for "SO" Tractor

1шт.

SCREW, 1/4" x 1/2" oval head steel machine, N.C. thread, orchard side fenders and crowl for "SO" Tractor

7шт.

SCREW, 1/4" x 3/4" oval head steel machine, N.C. thread, orchard side fenders and crowl for "SO" Tractor

5шт.

NUT, 1/4" hexagon, N.C. thread, orchard side fenders and crowl for "SO" Tractor

12шт.

WASHER, 1/4" standard lock, orchard side fenders and crowl for "SO" Tractor

12шт.

WASHER, 1/2" standard lock, orchard side fenders and crowl for "SO" Tractor

1шт.

A2654AA

SHEET, outer extension, R.H. fender. Tractor No. 4900000 and after, orchard side fenders and crowl for "SO" Tractor

1шт.

BOLT, 1/2" x 2" carriage, with hex nut, orchard side fenders and crowl for "SO" Tractor

1шт.

SCREW, 1/4" x 1/2" truss head machine, N.C. thread, with hexagon nut, orchard side fenders and crowl for "SO" Tractor

2шт.

SCREW, 1/4" x 3/4" truss head machine, N.C. thread, with hexagon nut, orchard side fenders and crowl for "SO" Tractor

5шт.

WASHER, 1/4" standard lock, orchard side fenders and crowl for "SO" Tractor

7шт.

WASHER, 1/2" standard lock, orchard side fenders and crowl for "SO" Tractor

1шт.

2655AA

SHEET, outer extension, L.H. fender. Prior to tractor to No. 4900000, orchard side fenders and crowl for "SO" Tractor

1шт.

BOLT, 1/2" x 2" carriage, with hex nut, orchard side fenders and crowl for "SO" Tractor

1шт.

SCREW, 1/4" x 1/2" oval head steel machine, N.C. thread, orchard side fenders and crowl for "SO" Tractor

7шт.

SCREW, 1/4" x 3/4" oval head steel machine, N.C. thread, orchard side fenders and crowl for "SO" Tractor

5шт.

NUT, 1/4" hexagon, N.C. thread, orchard side fenders and crowl for "SO" Tractor

12шт.

WASHER, 1/4" standard lock, orchard side fenders and crowl for "SO" Tractor

12шт.

WASHER, 1/2" standard lock, orchard side fenders and crowl for "SO" Tractor

1шт.

A2655AA

SHEET, outer extension, L.H. fender. Tractor No. 4900000 and after, orchard side fenders and crowl for "SO" Tractor

1шт.

BOLT, 1/2" x 2" carriage, with hex nut, orchard side fenders and crowl for "SO" Tractor

1шт.

SCREW, 1/4" x 1/2" truss head machine, N.C. thread, with hexagon nut, orchard side fenders and crowl for "SO" Tractor

2шт.

SCREW, 1/4" x 3/4" truss head machine, N.C. thread, with hexagon nut, orchard side fenders and crowl for "SO" Tractor

5шт.

WASHER, 1/4" standard lock, orchard side fenders and crowl for "SO" Tractor

7шт.

WASHER, 1/2" standard lock, orchard side fenders and crowl for "SO" Tractor

1шт.

5472A

SUPPORT, fender. Use A5472A, rear wheel fenders for "S" tractors

1шт.

A5472A

SUPPORT, fender, S, rear wheel fenders for "S" tractors

2шт.

O4709AB

STRAP, fender support. Use O6577AB, rear wheel fenders for "S" tractors

2шт.

O6467AB

BRACKET, fender to platform. Prior to tractor No. 4600000. See O7308AB - O7309AB, S, rear wheel fenders for "S" tractors

2шт.

O6577AB

BOLT, "U", fender support, S, rear wheel fenders for "S" tractors

2шт.

NUT, 5/8" hexagon, N.C. thread, S, rear wheel fenders for "S" tractors

4шт.

WASHER, 5/8" standard lock, S, rear wheel fenders for "S" tractors

4шт.

O7308AB

BRACKET, fender to platform, R.H. tractor No. 4600000 and after. See O6467AB, S, rear wheel fenders for "S" tractors

1шт.

O7309AB

BRACKET, fender to platform, L.H. tractor No. 4600000 and after. See O6467AB, S, rear wheel fenders for "S" tractors

1шт.

2616AA

FENDER, R.H. Use 3022AA, rear wheel fenders for "S" tractors

1шт.

2617AA

FENDER, L.H. Use 3023AA, rear wheel fenders for "S" tractors

1шт.

3022AA

FENDER, R.H., S, rear wheel fenders for "S" tractors

1шт.

SCREW, 7/16" x 1-3/4" hexagon head cap, N.F. thread, S, rear wheel fenders for "S" tractors

4шт.

NUT, 7/16" hexagon, light, N.F. thread, S, rear wheel fenders for "S" tractors

4шт.

WASHER, 7/16" standard lock, S, rear wheel fenders for "S" tractors

4шт.

3023AA

FENDER, L.H., S, rear wheel fenders for "S" tractors

1шт.

SCREW, 7/16" x 1-3/4" hexagon head cap, N.F. thread, S, rear wheel fenders for "S" tractors

4шт.

NUT, 7/16" hexagon, light, N.F. thread, S, rear wheel fenders for "S" tractors

4шт.

WASHER, 7/16" standard lock, S, rear wheel fenders for "S" tractors

4шт.

5676A

SUPPORT, fender. Use A5676A, rear wheel fenders for "S" tractors

1шт.

A5676A

SUPPORT, fender. Prior to tractor No. 5409579. See 3832AA, 3833AA, SC, rear wheel fenders for "SC" tractor

2шт.

O4709AB

STRAP, fender support. Use O7109AB, rear wheel fenders for "SC" tractor

1шт.

O7109AB

BOLT, "U" fender support. Prior to tractor No. 5409579. See O8539AB, SC, rear wheel fenders for "SC" tractor

2шт.

NUT, 5/8" hexagon, N.C. thread, SC, rear wheel fenders for "SC" tractor

4шт.

WASHER, 5/8" standard lock, SC, rear wheel fenders for "SC" tractor

4шт.

WASHER, 5/8" plain, SC, rear wheel fenders for "SC" tractor

4шт.

O8539AB

BOLT, "U" fender support. Tractor No. 5409579 and after. See O7109AB, SC, rear wheel fenders for "SC" tractor

2шт.

1870AA

FENDER, R.H. or L.H. prior to tractor No. 4600000. Use 2652AA, R.H. or 2653AA L.H. fender. See 2918AA or 3831AA, rear wheel fenders for "SC" tractor

1шт.

SCREW, 3/8" x 1-3/4" hexagon head cap, N.F. thread, SC, rear wheel fenders for "SC" tractor

8шт.

NUT, 3/8" hexagon, light, N.F. thread, SC, rear wheel fenders for "SC" tractor

8шт.

WASHER, 3/8" standard lock, SC, rear wheel fenders for "SC" tractor

8шт.

2918AA

FENDER, R.H. or L.H. Tractor No. 4600000 to no. 5409579. Use 3022AA R.H. or 3023AA L.H. fender. See 1870AA or 3831AA, rear wheel fenders for "SC" tractor

1шт.

SCREW, 7/16" x 2" hexagon head cap, N.F. thread, SC, rear wheel fenders for "SC" tractor

8шт.

NUT, 7/16" hexagon, light, N.F. thread, SC, rear wheel fenders for "SC" tractor

8шт.

WASHER, 7/16" standard lock, SC, rear wheel fenders for "SC" tractor

8шт.

3831AA

FENDER, R.H. or L.H. Tractor No. 5409579 and after. See 1870AA or 2918AA., SC, rear wheel fenders for "SC" tractor

2шт.

3832AA

SUPPORT, R.H. fender. Tractor No. 5409579 and after. See A5676A 3833AA, SC, rear wheel fenders for "SC" tractor

1шт.

3833AA

SUPPORT, L.H. fender. Tractor No. 5409579 and after. See A5676A 3832AA, SC, rear wheel fenders for "SC" tractor

1шт.
