Запчасти Case IH SC-SERIES (125) - POWER TAKE OFF ASSEMBLY WITH 1-3/8 INCH SHAFT, FOR SC AND SO TRACTOR WITH LONG SHAFT (06) - POWER TRAIN

A4826A

SLEEVE, extension, for SC tractor without motor lift. For SC and SO tractors with motor lift use 1621AA housing

1шт.

SCREW, 1/2" x 1-1/4" hexagon head cap, N.C. thread

3шт.

SCREW, 1/2" x 1-1/2" hexagon head cap, N.C. thread

1шт.

WASHER, 1/2" standard lock

4шт.

B4827A

CARRIER, rear bearing, 1-3/8" shaft

1шт.

FITTING, 1/8" straight Lincoln No. 5000, 1-3/8" shaft

1шт.

4946A

CARRIER, front bearing. Use O8301AB

1шт.

5367A

CARRIER, front bearing, 1-1/8" shaft

1шт.

5368A

CARRIER, rear bearing, 1-1/8" shaft

1шт.

5369A

COVER, rear, transmission case

1шт.

PLUG, 1/4" pipe

1шт.

PLUG, 1/2" pipe

1шт.

PLUG, 1-1/4" pipe

1шт.

SCREW, 1/2" x 1-1/4" hexagon head cap, N.C. thread

4шт.

SCREW, 1/2" x 1-3/4" hexagon head cap, N.C. thread

4шт.

WASHER, 1/2" standard lock

8шт.

5679A

RING, front bearing, 1-1/8" shaft

1шт.

O1455AB

X

CUP, power take-off shaft bearing, rear, Timken No. 2720, 1-3/8" shaft

1шт.

O1461AB

X

CUP, power take-off shaft bearing, Timken No. 14274, 1-1/8" shaft

2шт.

O1462AB

X

CONE, power take-off shaft bearing, Timken No. 14125, 1-1/8" shaft

2шт.

O1615AB

X

GASKET, transmission case rear cover

1шт.

O1616AB

COVER, power take-off, front

1шт.

O2924AB1

SPACER, power take-off shaft, short, 1-3/8" shaft

1шт.

O2925AB1

COLLAR, power take-off shaft, 1-3/8" shaft

1шт.

O2926AB

SPACER, power take-off shaft, long, 1-3/8" shaft

1шт.

O2930AB1

GASKET, extension sleeve

1шт.

O3347AB

SHIM, rear bearing carrier, (.0125" thick)

8шт.

O3348AB

SHIM, rear bearing carrier (.005" thick)

6шт.

O3351AB

CONE, bearing, rear, Timken No. 2796, 1-3/8" shaft

1шт.

O3352AB

CUP, bearing, front, Timken No. 16284, 1-3/8" shaft

1шт.

O3353AB

X

CONE, bearing, front, Timken No. 16150, 1-3/8" shaft

1шт.

O3869AB

X

SEAL, oil, power take-off shaft, 1-1/8" shaft

1шт.

O3899AB

X

SEAL, oil, power take-off shaft, 1-3/8" shaft

1шт.

O4567AB1

SPACER, power take-off shaft, long, 1-1/8" shaft

1шт.

O4568AB1

SPACER, power take-off shaft, short, 1-1/8" shaft

1шт.

O5386AB

PLATE, mounting, power take-off guard

1шт.

BOLT, 3/8" x 1" carriage, with hexagon nut

2шт.

SCREW, 3/8" x 1-5/8" hexagon head cap, N.C. thread

4шт.

WASHER, 3/8" standard lock

4шт.

WASHER, 3/8" type 40, 4020-26 Shakeproof lock

2шт.

WASHER, 3/8" plain

2шт.

O5900AB

SHAFT, power take-off. (1-1/8" x 48-5/8" long). Prior to tractor No. 4706368. See O6602AB, 1-1/8" shaft

1шт.

O5902AB

GEAR, power take-off. Prior to tractor No. 4706368., 1-1/8" shaft

1шт.

O5903AB

BEARING, BALL

BEARING, power take-off shaft pilot, New Departure no. 3204

1шт.

O5904AB

RING, SNAP

RING, power take-off shaft snap

1шт.

O6300AB

GASKET, power take-off front cover

1шт.

O6487AB

THIMBLE for installing O3869AB oil seal, 1-3/8" shaft

1шт.

O6491AB

THIMBLE for installing O3899AB oil seal, 1-3/8" shaft

1шт.

O6602AB

SHAFT, power take-off. (1-3/8" x 48-19/32" long). Tractor No. 4706368 and after. See O5900AB, 1-3/8" shaft

1шт.

KEY, No. 15 Woodruff, 1-3/8" shaft

2шт.

O6603AB

GEAR, power take-off, 1-3/8" shaft

1шт.

O8301AB

CARRIER, front bearing, 1-3/8" shaft

1шт.

O8303AB

X

GUARD, power take-off, 1-3/8" shaft

1шт.

O8794AB

GUARD, tubular, end of power take-off shaft

1шт.

A623AA

GUARD, tubular, end of power take-off shaft. Use O8794AB.

1шт.

736AA

SUPPORT, with spring, for power take-off front cover

1шт.

SCREW, 1/2" x 1-3/4" hexagon head cap, N.F. thread

1шт.

WASHER, 1/2" standard lock

1шт.

2172AA

X

GUARD, with top plate and braces. Use O8303AB

1шт.

3337AA

PARTS necessary to convert "SC" tractor, equipped with 1-1/8" spline shaft and power lift to a 1-3/8" spline shaft. Consists of the following:

1шт.

B4827A

REAR bearing carrier, 1-3/8" shaft

1шт.

1/8" straight Lincoln fitting, No. 5000, 1-3/8" shaft

1шт.

O1455AB

X

CUP for Timken bearing (PTO shaft), 1-3/8" shaft

1шт.

O2924AB1

PTO shaft spacer, 1-3/8" shaft

1шт.

O2925AB1

PTO shaft collar, 1-3/8" shaft

1шт.

O2932AB

POWER lift driving worm, 1-3/8" shaft

1шт.

O3344AB

POWER lift housing gasket, 1-3/8" shaft

1шт.

O3347AB

BEARING carrier shim, 1-3/8" shaft

1шт.

O3348AB

BEARING carrier shim, 1-3/8" shaft

2шт.

O3351AB

PTO shaft bearing cone - rear, 1-3/8" shaft

1шт.

O3352AB

PTO shaft bearing cup - front, 1-3/8" shaft

1шт.

O3353AB

X

PTO shaft bearing cone - front, 1-3/8" shaft

1шт.

O3899AB

X

PTO shaft oil seal, 1-3/8" shaft

1шт.

O6602AB

PTO shaft, 1-3/8" shaft

1шт.

No. 15 Woodruff key, 1-3/8" shaft

2шт.

O6603AB

PTO gear, 1-3/8" shaft

1шт.

O6604AB

PTO shifter fork, 1-3/8" shaft

1шт.

O7185AB

X

TRANSMISSION case top cover gasket, 1-3/8" shaft

1шт.

O8301AB

FRONT bearing carrier, 1-3/8" shaft

1шт.
