(053) - SMALL GASOLINE TANK AND ENGINE HOOD FOR LOW COST FUEL, S, SC, SO, 06414AB TWO WAY FUEL STRAINER

Запчасти Case IH S-SERIES (053) - SMALL GASOLINE TANK AND ENGINE HOOD FOR LOW COST FUEL, S, SC, SO, 06414AB TWO WAY FUEL STRAINER (03) - FUEL SYSTEM

Схема запчастей Case IH S-SERIES - (053) - SMALL GASOLINE TANK AND ENGINE HOOD FOR LOW COST FUEL, S, SC, SO, 06414AB TWO WAY FUEL STRAINER (03) - FUEL SYSTEM
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

F1X24

GASKET, bowl

1шт.

F2X1

ELEMENT, filter

1шт.

F7X114

HEAD, filter bowl

1шт.

CONNECTOR, 1/8" pipe thread x 5/16" tube size, Dole A3 male

1шт.

F8X4

BOWL, filter

1шт.

F25X12

VALVE, shut-off

1шт.

F110X9

BAIL, glass bowl

1шт.
