Запчасти Case IH LA-SERIES (017) - REAR TRACTOR LAMP (04) - ELECTRICAL SYSTEMS

5423a

5423A

BRACKET for white rear lamp mounted on fender

1шт.

SCREW cap, hex head, N.F. thread, 3/8" x 1-1/4", for white rear lamp mounted on fender

2шт.

NUT hex, light, N.F. thread, 3/8", for white rear lamp mounted on fender

2шт.

WASHER lock, standard, 3/8", for white rear lamp mounted on fender

2шт.

a5804a

A5804A

BRACKET combination flood and red tail lamp (Prior to Tractor No. 5509680) (See 6123A)

1шт.

SCREW cap, hex head, N.F. thread, 5/16" x 1", for combination flood and red tail light

2шт.

NUT hex, light, N.F. thread, 5/16", for combination flood and red tail light

2шт.

WASHER lock, standard, 5/16", for combination flood and red tail light

2шт.

6123a

A34046

BRACKET

for combination flood and red tail light (Tractor No. 5509680 and after) (See A5804A)

1шт.

SCREW cap, hex head, N.F. thread, 3/8" x 1-1/2", for combination flood and red tail light

1шт.

SCREW cap, hex head, N.C. thread, 3/8" x 1-1/2", for combination flood and red tail light

2шт.

NUT hex, light, N.F. thread, 3/8", for combination flood and red tail light

1шт.

WASHER lock, standard, 3/8", for combination flood and red tail light

3шт.

02457ab

O2457AB

CLIP wire, for white rear lamp mounted on fender (Prior to tractor No. 5208165) (See O6168AB)

3шт.

06168ab

O6168AB

CLIP wire, for white rear lamp mounted on fender and combination flood and red tail light (Tractor No. 5208165 and after)

5шт.

SCREW machine, round head, N.C. thread, 1/4" x 1/2", for white rear lamp mounted on fender and combination flood and red tail light

5шт.

NUT hex, N.C. thread, 1/4", for white rear lamp mounted on fender and combination flood and red tail light

5шт.

WASHER lock, standard, 1/4", for white rear lamp mounted on fender and combination flood and red tail light

5шт.

06182ab

O6182AB

CLIP wire, rear lamp, on fender support angle, for combination flood and red tail light

2шт.

06225ab

O6225AB

REINFORCEMENT for 5423A white rear lamp bracket mounted on fender

1шт.

06225ab1

O6225AB1

REINFORCEMENT for A5804A rear lamp bracket, for combination flood and red tail light (See O8881AB)

1шт.

06752ab

O6752AB

LAMP white rear, mounted on fender

1шт.

06754ab1

O6754AB1

WIRE for white rear lamp mounted on fender (Prior to tractor No. 5208165) (See O8275AB)

1шт.

08275ab

O8275AB

WIRE for white rear lamp mounted on fender and combination flood and red tail light (Tractor No. 5208165 to No. 5509680) (See 06754AB1 and 08882AB)

1шт.

08276ab

O8276AB

LOOM for 08275AB white rear lamp wire mounted on fender and for combination flood and red tail light

1шт.

08332ab

A27338

GROMMET

rubber, 5/8" OD x 3/8" hole, No. 230, in fender, for white rear lamp wire and for combination flood and red tail light wire

1шт.

08810ab

A35194

HEADLIGHT

LAMP for combination flood and red tail light

1шт.

08881ab

O8881AB

REINFORCEMENT for 6123A rear lamp bracket, for combination flood and red tail light (See O6225AB1)

1шт.

08882ab

O8882AB

WIRE rear lamp, for combination flood and red tail light (Tractor No. 5509680 and after) (See O8275AB)

1шт.
