Запчасти Case IH DC-SERIES (064) - DIFFERENTIAL SHAFT ASSEMBLY, FOR "DC" - "DO" - "DV" TRACTORS (06) - POWER TRAIN

4612a

4612A

CARRIER, differential shaft bearing

2шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 1/2" x 1-1/2" hexagon head cap, N.C. thread

8шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 1/2" standard lock

8шт.

4613a

4613A

WHEEL, differential center

1шт.

nss

NSS

NOT SOLD SEPARAT

KEY, no. 29 Woodruff

1шт.

o1275ab

O1275AB

PLATE, differential shaft bearing

2шт.

o1276ab

O1276AB

SCREW, differential shaft plate

4шт.

nss

NSS

NOT SOLD SEPARAT

WIRE, no. 16 gauge x 4" soft sealed annealed iron

2шт.

o1279ab

O1279AB

BOLT, differential center wheel

6шт.

nss

NSS

NOT SOLD SEPARAT

NUT, 1/2"-20 castle, light, N.F. thread

6шт.

nss

NSS

NOT SOLD SEPARAT

PIN, 3/32" x 7/8" cotter

6шт.

o1460ab

O1460AB

BEARING, CUP

CUP, differential shaft bearing. Timken no. 453A

2шт.

o1642ab

O1642AB

SHIM, differential shaft bearing carrier, thick, no. 30 gauge

12шт.

o1644ab

O1644AB

GEAR, differential spur

1шт.

o1645ab

O1645AB

PINION, differential

3шт.

o1646ab

O1646AB

PIN, differential pinion

3шт.

o1647ab

O1647AB

WASHER, thrust, differential shaft

2шт.

o1689ab

O1689AB

SHAFT, differential

1шт.

o1772ab

O1772AB

SHIM, differential shaft bearing, thin, .005"

12шт.

o1856ab

O1856AB

CONE, differential shaft bearing. Timken no. 460

2шт.

o4991ab

O4991AB

GEAR AND SPROCKET, differential. (On "D" and "DH" tractors with independent brakes, O4992AB gear and sprocket must be used) (D, DH)

2шт.

o4492ab

O4492AB

X

GEAR AND SPROCKET, differential (DC, DO, DV)

2шт.
