Запчасти Case IH DC-SERIES (104) - DUAL FRONT WHEEL FOR PNEUMATIC FARM TIRES, FOR "DC" TRACTOR (06) - POWER TRAIN

C4949A

WHEEL, front. Use C1143AA

1шт.

5506A

LUG, front wheel rim, used to provide wide tread for listing work (4 used on each wheel)

8шт.

5818A

WHEEL, reversible front. Tractor no. 4607033 and after. See D1151AA

2шт.

SCREW, 5/8" x 2-1/4" hexagon head cap, N.C. thread

6шт.

WASHER, 5/8" standard lock

6шт.

5819A

HUB, reversible front wheel. Tractor no. 4607033 and after. Use 2989AA

1шт.

O1461AB

X

CUP, front wheel outer bearing, Timken no. 14274

2шт.

O7057AB

X

CUP, front wheel inner bearing, Timken no. 354A

2шт.

O7241AB

X

STUD, front wheel rim (Goodyear no. 46) for C1143AA wheel

8шт.

O7242AB

NUT, front wheel rim stud (Goodyear no. 35) for C1142AA wheel

8шт.

O7554AB

RIM, front wheel (4.50 E-16 full drop center rim without drive lugs) for C1142AA wheel

2шт.

O7586AB

X

CLAMPS, front wheel rim (Goodyear no. 312) for C1142AA wheel

8шт.

C1142AA

WHEEL, front, complete. Prior tractor no. 4607033. See 5818A, 2989AA, and D1151AA. Consists of: 1 - C1143AA, 1 - O7554AB, 4 - O7586AB, and 4 - O7242AB

2шт.

C1143AA

WHEEL, front, with bearing cups, less rim. Prior to tractor no. 4607033. See 2989AA. Consists of: 1 - C4949A, 1 - O1461AB, 1 - O7057AB, and 4 - O7241AB

2шт.

D1151AA

WHEELS, front set of (2) reversible. Tractor no. 4607033 and after. Consists of: 2 - 2989AA, 2 - 5818A, 6 - 5/8" x 2-1/4" hexagon head cap screws, N.C. thread and 6 - 5/8" lockwashers (Machy. item)

1шт.

2989AA

HUB, reversible front wheel, with bearing cups. Tractor no. 4607033 and after. Consists of: 1 - 5819A, 1 - O1461AB, and 1 - O7057AB

2шт.

B4690A

WHEEL, cast front. (25" diameter x 4" wide). Use A315AA

1шт.

O1461AB

X

CUP, front wheel outer bearing, Timken no. 14274

2шт.

O7057AB

X

CUP, front wheel inner bearing, Timken no. 354A

2шт.

A315AA

WHEEL, front with bearing cups, less rim. Consists of: 1 - B4690A, 1 - O1461AB, and 1 - O7057AB

2шт.
