Запчасти Case IH DC-SERIES (130) - STEERING GEAR ASSEMBLY, FOR "DC" TRACTORS PRIOR TO NUMBER 4607033 (05) - STEERING

A7668

WHEEL

steering

1шт.

B5391A

COLUMN, steering shaft

1шт.

SCREW, 1/2" x 1-1/2" hexagon head cap, N.C. thread

3шт.

SCREW, 1/2" x 3/4" hexagon head cap, N.C. thread

2шт.

WASHER, 1/2" standard lock

3шт.

FITTING, 1/8" - 45 degree Lincoln no. 5200

1шт.

O1241AB

BALL, steering drop arm

1шт.

O1450AB

WASHER, steering shaft trust

1шт.

O1532AB

WASHER, steering shaft

2шт.

O1674AB

SHAFT, steering arm and worm wheel

1шт.

NUT, 7/8" castle, light, N.F. thread

2шт.

PIN, 1/8" x 1-1/4" cotter

2шт.

O1675AB

WHEEL, steering worm DC3

1шт.

O2003AB

X

SCREW, drag link adjusting

2шт.

PIN, 1/8" x 2" cotter

2шт.

O2004AB

BEARING, drag link

4шт.

O2005AB

X

SPRING, drag link

2шт.

O2066AB1

WORM, steering DC3

1шт.

KEY, no. 127 Woodruff

2шт.

O2764AB

WORM, steering DC4

1шт.

KEY, no. 127 Woodruff

1шт.

O2765AB

WHEEL - steering worm DC4

1шт.

O2856AB

WASHER, steering drop arm shaft

2шт.

O3430AB1

BUSHING, steering drop arm shaft, outer

1шт.

O3938AB

X

SEAT AND SPACER, drag link

2шт.

O4240AB

X

SEAL, oil, steering drop arm shaft

1шт.

O4935AB

X

WHEEL, steering. Use A7668

1шт.

O4995AB

X

KNOB, for O4935AB steering wheel

1шт.

O4996AB

BOLT, for O4995AB knob

1шт.

NUT, 3/8" hexagon, jam, N.C. thread

1шт.

WASHER, 3/8" standard lock

1шт.

WASHER, 3/8" standard plain

2шт.

O5004AB

GASKET, steering shaft column

1шт.

O5833AB

SHAFT, steering wheel

1шт.

KEY, no. 127 Woodruff

1шт.

NUT, 3/4" hexagon, jam, N.C. thread

1шт.

NUT, 3/4" castle, N.C. thread

1шт.

PIN, 1/8" x 1-1/4" cotter

1шт.

O5834AB

COLLAR, steering shaft

1шт.

PIN, 3/8" x 2-1/4" full length taper groove, type 1

1шт.

O5912AB

BEARING, steering shaft thrust

1шт.

O7174AB1

SCREW, adjusting steering drop arm shaft

1шт.

VT3397

WOODRUFF KEY - steering shaft

1шт.

A212AA

LINK, steering drag DC3

1шт.

FITTING, 1/8" straight Lincoln, no. 5000

2шт.

A323AA

ARM, steering drop, with ball DC3

1шт.

A2031AA

STOP, with support, steering drop arm

1шт.

SCREW, 1/2" x 2-1/2" hexagon head cap, N.C. thread

2шт.

2844AA

LINK, steering drag DC4

1шт.

2907AA

ARM, steering drop with ball DC4

1шт.
