Запчасти Case IH D-SERIES (140) - DRAW BAR ASSEMBLY, FOR "D" TRACTOR - PRIOR TO NO. 4402685 (09) - CHASSIS

o909ab

O909AB

BOLT, drawbar pivot

1шт.

nss

NSS

NOT SOLD SEPARAT

NUT, 3/4" hexagon, light, N.F. thread

1шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 3/4" standard lock

1шт.

o1890ab

O1890AB

ANGLE, draw bar guide. Prior to tractor no. 4402517. See 2262AA (DO)

1шт.

o1892ab

O1892AB

STRAP, draw bar, rear

1шт.

nss

NSS

NOT SOLD SEPARAT

RIVET, 5/8" x 1-7/8" round head

2шт.

o1893ab

O1893AB

STRAP, drawbar, front

1шт.

nss

NSS

NOT SOLD SEPARAT

RIVET, 1/2" x 1-1/8" round head

2шт.

o1894ab1

O1894AB1

ROLLER, draw bar

1шт.

o1895ab1

O1895AB1

BOLT, draw bar roller

1шт.

nss

NSS

NOT SOLD SEPARAT

NUT, 3/4" hexagon, light, N.F. thread

1шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 3/4" standard lock

1шт.

167aa

167AA

BAR, draw. Prior to tractor no. 4402517. Consists of draw bar, front and rear straps, roller and bolt. See 603AA (DO)

1шт.

603aa

603AA

BAR, draw. Tractor no. 4402517 and after. Consists of draw bar, front and rear straps, roller and bolt. See 167AA (DO)

1шт.

603aa

603AA

BAR, draw, complete with straps, roller and bolt (D, DC, DH, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

BOLT, 5/8" x 1-1/4" machine, with hex nut (DC, DH)

1шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 5/8" standard lock (DC, DH)

1шт.

1943aa

1943AA

ANGLE, guide, with supports. Prior to tractor no. 4402685 (D)

1шт.

1943aa

1943AA

ANGLE, guide, with supports and brace (DC, DH)

1шт.

2262aa

2262AA

ANGLE, guide, with supports. Tractor no. 4402685 and after (D)

1шт.

2262aa

2262AA

ANGLE, guide, with supports. Tractor no. 4402517 and after. See O1890AB (DO)

1шт.

2262aa

2262AA

ANGLE, guide, with supports (DV)

1шт.
