Запчасти Case IH D-SERIES (128) - POWER TAKE-OFF ASSEMBLY, FOR "D" - "DH" TRACTORS - PRIOR TO (06) - POWER TRAIN

a4541a

A4541A

CAP, power take-off shaft rear cover (D, DH, DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 1/2" x 1-1/4" hexagon head cap, N.C. thread (D, DH, DO, DV)

4шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 1/2" standard lock (D, DH, DO, DV)

4шт.

4542a

4542A

GUARD, power take-off shaft. (Used with O1922AB shaft) (D, DH)

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 1/2" x 1-1/4" hexagon head cap, N.C. thread (D, DH)

1шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 1/2" standard lock (D, DH)

1шт.

4660a

4660A

COVER, transmission case rear (D, DH, DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 1/2" x 1-1/4" hexagon head cap, N.C. thread (D, DH, DO, DV)

10шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 1/2" standard lock (D, DH, DO, DV)

10шт.

nss

NSS

NOT SOLD SEPARAT

PLUG, 1-1/4" square head pipe (D, DH, DO, DV)

1шт.

o6693a

O6693A

BEARING, front end, power take-off shaft, New Departure no. 1305 (D, DH, DO, DV)

1шт.

o719ab

O719AB

GASKET, rear cover cap (D, DH, DO, DV)

1шт.

o809ab

O809AB

SPRING, power take-off shifter (D, DH, DO, DV)

1шт.

o907ab

O907AB

WASHER, power take-off shaft, front end (D, DH, DO, DV)

1шт.

o1615ab

O1615AB

X

GASKET, transmission case rear cover (D, DH, DO, DV)

1шт.

o1616ab

O1616AB

COVER, front end, power take-off (D, DH, DO, DV)

1шт.

o1720ab

O1720AB

BEARING

rear end, power take-off shaft, New Departure no. 1207 (D, DH, DO, DV)

1шт.

o1815ab

O1815AB

X

NUT, power take-off shaft, front end (D, DH, DO, DV)

1шт.

o1816ab

O1816AB

WASHER, power take-off shaft, front end (D, DH, DO, DV)

1шт.

o1818ab

O1818AB

CLUTCH, power take-off shaft gear (D, DH, DO, DV)

1шт.

o1822ab

O1822AB

X

COLLAR, power take-off shaft (D, DH, DO, DV)

1шт.

o1823ab1

O1823AB1

SPACER, power take-off shaft. (Used with O1922AB shaft) (D, DH)

1шт.

o1823ab2

O1823AB2

X

SPACER, power take-off shaft. (Used with O5400AB shaft) (D, DH, DO, DV)

1шт.

o1916ab1

O1916AB1

ROD, power take-off shifter. Prior to tractor no. 4304633 (D, DH)

1шт.

nss

NSS

NOT SOLD SEPARAT

BALL, 7/16" hard steel (D, DH)

1шт.

o1916ab2

O1916AB2

ROD, power take-off shifter. Tractor no. 4304633 and after (D, DH)

1шт.

nss

NSS

NOT SOLD SEPARAT

BALL, 7/16" hard steel (D, DH)

1шт.

o1916ab2

O1916AB2

ROD, power take-off shifter (DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

BALL, 7/16" hard steel (DO, DV)

1шт.

o1920ab

O1920AB

FORK, power take-off shifter (D, DH, DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 3/8" x 1-1/4" hexagon head cap, N.C. thread (D, DH, DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 3/8" standard lock (D, DH, DO, DV)

1шт.

o1922ab

O1922AB

SHAFT, power take-off (1-3/8" spline x 42-1/4" long). Used with 4542A guard (D, DH)

1шт.

o2144ab

O2144AB

X

GASKET, front cover, power take-off (D, DH, DO, DV)

1шт.

o2849ab

O2849AB

SPACER, power take-off guard mounting plate (D, DH, DO, DV)

4шт.

o3899ab

O3899AB

X

SEAL, oil, power take-off shaft (D, DH, DO, DV)

1шт.

o4811ab

O4811AB

X

RING, snap, power take-off shift rod. Prior to tractor no. O4811AB (D, DH)

2шт.

o4907ab

O4907AB

LEVER AND LINK, shifter rod. Prior to tractor no. 4304633 (D, DH)

1шт.

o4907ab1

O4907AB1

LEVER AND LINK, shifter rod. Tractor no. 4304633 and after (D, DH)

1шт.

nss

NSS

NOT SOLD SEPARAT

PIN, 1/4" x 2" cotter (D, DH)

1шт.

o4907ab1

O4907AB1

LEVER AND LINK, shifter rod (DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

PIN, 1/4" x 2" cotter (DO, DV)

1шт.

o4908ab

O4908AB

SUPPORT, shifter rod link (DH)

1шт.

o4908ab

O4908AB

SUPPORT, shifter rod link. Prior to tractor no. 4402685 (D)

1шт.

o4910ab

O4910AB

SUPPORT, shifter rod link. Tractor no. 4402685 and after (D)

1шт.

o4910ab

O4910AB

SUPPORT, shifter rod link. See O5533AB (DO, DV)

1шт.

o5382ab

O5382AB

RING, snap, power take-off shaft. (Used with O5400AB) shaft (D, DH, DO, DV)

1шт.

o5386ab

O5386AB

PLATE, mounting, power take-off guard (D, DH, DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

BOLT, 3/8" x 1" carriage, with hex. nut (D, DH, DO, DV)

2шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 1/2" x 1-3/4" hexagon head cap, N.C. thread (D, DH, DO, DV)

4шт.

nss

NSS

NOT SOLD SEPARAT

BOLT, 3/8" x 3/4" machine, with hex. nut (D, DH, DO, DV)

2шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 3/8" standard lock (D, DH, DO, DV)

2шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 3/8" Shakeproof lock, type 40, no. 4020-26 (D, DH, DO, DV)

2шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 1/2" standard lock (D, DH, DO, DV)

4шт.

o5400ab

O5400AB

SHAFT, power take-off, (1-3/8" spline x 42-1/4" long). Used with A623AA tubular shield (D, DH, DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

PIN, 1/8" x 1-1/4" cotter (D, DH, DO, DV)

1шт.

o5533ab

O5533AB

SUPPORT, shifter rod link. (Used only with electric lighting and starting attachment). See O4910AB (DO, DV)

1шт.

o5534ab

O5534AB

STOP, shifter rod, (Used with O1916AB1). Prior to tractor no. 4304633 (D, DH)

1шт.

o6102ab

O6102AB

BUSHING, power take-off gear (D, DH, DO, DV)

1шт.

o7603ab

O7603AB

PINION, power take-off drive. For tractors having 3261AA transmission gear assembly field change (D, DH, DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

KEY, no. B. Woodruff (D, DH, DO, DV)

1шт.

a381aa

A381AA

GEAR, power take-off, with bushing, (39 teeth), for 2142AA and 2143AA bevel gears. See 2872AA (D, DH, DO, DV)

1шт.

a623aa

A623AA

SHIELD, tubular, power take-off shaft end. (Used with O4500AB shaft) (D, DH, DO, DV)

1шт.

736aa

736AA

SUPPORT, with spring, power take-off front cover (D, DH, DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 1/2" x 1-3/4" hexagon head cap, N.C. thread (D, DH, DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 1/2" standard lock (D, DH, DO, DV)

1шт.

1966aa

1966AA

GUARD, power take-off, with supports. Use 2255AA (D, DH, DO, DV)

1шт.

2172aa

2172AA

X

GUARD, power take-off (D, DH, DO, DV)

1шт.

2255aa

2255AA

1шт.

GUARD, power take-off, complete. (To be ordered in place of 1966AA). Consists of 1 - 2172AA guard, 4 - O2849AB spacers, 1 - O5386AB plate, 2-3/8" x 1" carriage bolts, 4-1/2" x 1-3/4" cap screws, 4-3/8" x 1-3/8" cap screws, 2-3/8" Shakeproof lockwashers and 2-3/8" plain washers (D, DH, DO, DV)

1шт.

2872aa

2872AA

GEAR, power take-off, with bushing, (40 teeth), for 3261AA bevel gears. See A381AA (D, DH, DO, DV)

1шт.
