Запчасти Case IH D-SERIES (016) - MANIFOLD, CARBURETOR AND AIR CLEANER ASSEMBLY, FOR LOW COST FUEL (02) - ENGINE

4363a

4363A

NUT, air cleaner clamp

1шт.

a4440a

A4440A

ADAPTER, for O169AB3 carburetor. Prior to tractor no. 4301200. See 5392A or 5504A

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 5/16" x 3/4" hexagon head cap, N.C. thread

2шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 5/16" standard lock

2шт.

4577a

4577A

MANIFOLD, intake

1шт.

nss

NSS

NOT SOLD SEPARAT

PLUG, 1/8" square head pipe

2шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 3/8" x 7/8" hexagon head cap, N.C. thread

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 3/8" x 2-1/4" hexagon head cap, N.C. thread

2шт.

4578a

4578A

MAINFOLD, exhaust

1шт.

4579a

4579A

BODY, air cleaner. Prior to tractor no. 4405821. See 5502A

1шт.

4580a

4580A

RESERVOIR, air cleaner. Prior to tractor no. 4405821. See 5503A

1шт.

4581a

4581A

FLANGE, air intake pipe. Prior to tractor no. 4405821. See 5509A (D, DC, DH)

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 3/8" x 1" hexagon cap, N.C. thread (D, DC, DH)

1шт.

4684a

4684A

ELBOW, air intake (DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 3/8" x 2-1/4" hexagon head cap, N.C. thread (DO, DV)

1шт.

4992a

4992A

X

ELBOW, exhaust. See 5220A (D, DC, DH)

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 3/8" x 2-1/4" hexagon, N.C. thread (D, DC, DH)

2шт.

5023a

5023A

LEVER, heat regulator rod link. Use O4801AB1

1шт.

nss

NSS

NOT SOLD SEPARAT

PIN, 1/8" x 3/4" type 1 full length tapered groove

1шт.

5220a

5220A

ELBOW, exhaust. See 4992A (DO, DV)

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 3/8" x 1" hexagon head cap, N.C. thread (DO, DV)

2шт.

5317a

5317A

VALVE, heat regulator

1шт.

5318a

5318A

LEVER, heat regulator

1шт.

nss

NSS

NOT SOLD SEPARAT

BOLT, 3/8" x 6-1/4" machine, with hex. nut

1шт.

nss

NSS

NOT SOLD SEPARAT

NUT, 3/8" hexagon jam, N.C. thread

1шт.

5392a

5392A

ADAPTER, for O4990AB carburetor. Tractor no. 4301201 to 4405821. See A4440A or 5504A

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 5/16" x 3/4" hexagon head cap, N.C. thread

2шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 5/16" standard lock

2шт.

5502a

5502A

BODY, air cleaner. Tractor no. 4405821 and after. See 4579A

1шт.

5503a

5503A

RESERVOIR, air cleaner. Tractor no. 4405821 and after. See 4580A

1шт.

5504a

5504A

ADAPTER, for O4990AB carburetor. Tractor no. 4508521 and after. See A4440A or 5392A

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 3/8" x 1-1/2" hexagon head cap, N.C. thread

2шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 3/8" standard lock

2шт.

5509a

5509A

FLANGE, air intake pipe. Tractor no. 4405821 and after. See 4581A (D, DC, DH)

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 3/8" x 1" hexagon head cap, N.C. thread (D, DC, DH)

1шт.

o887ab

O887AB

X

FERRULE, exhaust manifold

4шт.

o891ab

O891AB

MANIFOLD GASKET

intake and exhaust manfold

2шт.

o895ab

O895AB

CLAMP, air cleaner

1шт.

o896ab

O896AB

STUD, air cleaner clamp. Prior to tractor no. 4405821. See O1581AB

1шт.

nss

NSS

NOT SOLD SEPARAT

NUT, 3/8" hexagon

1шт.

o897ab

O897AB

STRAP, air cleaner clamp

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 5/16" x 3/4" hexagon head cap, N.C. thread

1шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 5/16" standard lock

1шт.

nss

NSS

NOT SOLD SEPARAT

NUT, 3/8" hexagon N.C. thread

1шт.

o920ab1

O920AB1

SPRING, heat regulator rod. Prior to tractor no. 4400143

1шт.

o1052ab

O1052AB

SCREEN, air intake (DO, DV)

1шт.

o1116ab1

O1116AB1

X

GASKET, carburetor adaptor

1шт.

o1117ab

O1117AB

SUPPORT, lower screen. Prior to tractor no. 4405821

2шт.

o1118ab

O1118AB

SUPPORT, air cleaner screen. Prior to tractor no. 4405821

1шт.

nss

NSS

NOT SOLD SEPARAT

BOLT, 1/4" x 1-3/4" machine, with square nut

2шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 1/4" standard lock

2шт.

o1119ab

O1119AB

SCREEN, air cleaner upper. Prior to tractor no. 4405821

13шт.

o1120ab

O1120AB

SCREEN, air cleaner lower. Prior to tractor no. 4405821

1шт.

o1141ab

O1141AB

SCREEN, reservoir. Prior to tractor no. 4405821

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 1/4"-20 x 5/8" rd. hd. machine, with nuts

2шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 1/4" standard lock

2шт.

o1575ab

O1575AB

SPACER, heat regulator valve

1шт.

o1579ab

O1579AB

STUD, carburetor to manifold, long. See O3626AB

1шт.

nss

NSS

NOT SOLD SEPARAT

NUT, 3/8" hexagon, light, N.F. thread

1шт.

o1581ab

O1581AB

STUD, air cleaner clamp. Tractor no. 4405821 and after. See O896AB

1шт.

o1596ab

O1596AB

CLAMP, manifold

2шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 3/8" x 1-1/2" cup point set

2шт.

nss

NSS

NOT SOLD SEPARAT

NUT, 3/8" hexagon, jam, N.C. thread

2шт.

o1598ab

O1598AB

REINFORCEMENT, oil reservoir gasket. Prior to tractor no. 4405821

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 1/4"-28 x 3/8" fillister head machine

4шт.

o1599ab

O1599AB

GASKET, oil reservoir. Prior to tractor no. 4405821

1шт.

o1607ab

O1607AB

STUD, air intake flange

1шт.

nss

NSS

NOT SOLD SEPARAT

NUT, 3/8" hexagon, light, N.F. thread

1шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 3/8" standard lock

1шт.

o1608ab

O1608AB

STUD, manifold clamp

4шт.

nss

NSS

NOT SOLD SEPARAT

NUT, 7/16" hexagon, light, N.F. thread

2шт.

o3475ab

O3475AB

PIPE, exhaust (D, DC, DH)

1шт.

o3626ab

O3626AB

STUD, carburetor to manifold, short. See O1579AB

1шт.

nss

NSS

NOT SOLD SEPARAT

NUT, 3/8" hexagon jam, light, N.F. thread

1шт.

o4050ab

O4050AB

NUT, manifold cover. Prior to tractor no. 4400143. See O5352AB

2шт.

o4157ab

O4157AB

VENTURI, inlet manifold

2шт.

o4260ab1

O4260AB1

LINK, heat regulator. Prior to tractor no. 4400143

1шт.

nss

NSS

NOT SOLD SEPARAT

PIN, 3/32" x 5/8" cotter

1шт.

o4309ab1

O4309AB1

CLIP, heat regulator rod, front. Prior to tractor no. 4400143

2шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 5/16" x 1/2" hexagon cap, N.C. thread

2шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 5/16" standard lock

2шт.

o4591ab

O4591AB

CLIP, flexible choke control. Prior to tractor no. 4405749

1шт.

o4591ab1

O4591AB1

CLIP, flexible choke control. Tractor no. 4405749 and after

1шт.

nss

NSS

NOT SOLD SEPARAT

BOLT, 3/16" x 3/4" rd. hd. stove

1шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 3/16" standard lock

1шт.

o4801ab1

O4801AB1

ROD, heat regulator, rear. Prior to tractor no. 4400143

1шт.

nss

NSS

NOT SOLD SEPARAT

PIN, 3/32" x 5/8" cotter

1шт.

o4802ab

O4802AB

LINK, heat regulator rod. Prior to tractor no. 4400143

1шт.

nss

NSS

NOT SOLD SEPARAT

PIN, 3/32" x 5/8" cotter

2шт.

o5320ab

O5320AB

SCREW, heat regulator clamp. Tractor no 4400143 and after

1шт.

o5321ab

O5321AB

BODY, heat regulator clamp screw. Tractor no. 4400143 an after

1шт.

nss

NSS

NOT SOLD SEPARAT

NUT, 5/8" hexagon jam, light, N.F. thread

1шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 5/8" standard lock

1шт.

o5346ab

O5346AB

RING, snap, heat regulator. Tractor no. 4400143 and after

1шт.

o5349ab

O5349AB

ROD, heat regulator control. Tractor no. 4400143 and after

1шт.

nss

NSS

NOT SOLD SEPARAT

PIN, 1/16" x 3/8" cotter

1шт.

o5350ab

O5350AB

ARM, heat regulator lever. Tractor no. 440143 and after

1шт.

o5351ab

O5351AB

LINK, heat regulator lever arm.Tractor no. 440143 and after

1шт.

nss

NSS

NOT SOLD SEPARAT

PIN, 1/16" x 3/8" cotter

1шт.

o5352ab

O5352AB

NUT, manifold cover. Tractor no. 4400143 and after. See O4050AB

2шт.

o5581ab

O5581AB

GASKET, air cleaner box plate. Tractor no. 4405821 and after

1шт.

o5582ab

O5582AB

PAD, air cleaner filter, lower. Tractor no 4405821 and after

1шт.

o5583ab

O5583AB

PAD, air cleaner filter, upper. Tractor no. 4405321 and after

1шт.

o5584ab

O5584AB

SCREEN, air cleaner, upper. Tractor no. 4405821 and after

1шт.

o5586ab

O5586AB

GASKET, air claener reservoir. Tractor no. 4405821 and after

1шт.

a207aa

A207AA

CLEANER, air, complete. Prior to tractor no. 4405821

1шт.

219aa

219AA

X

PIPE, air intake, complete. Prior to tractor no. 4405821. See 2358AA (D, DC, DH)

1шт.

1555aa

1555AA

SHIELD, manifold

1шт.

a1639aa

A1639AA

QUADRANT, heat regulator, with support. Prior to tractor no. 4400143

1шт.

nss

NSS

NOT SOLD SEPARAT

BOLT, 3/8" x 1" flat head stove

1шт.

nss

NSS

NOT SOLD SEPARAT

WASHER, 3/8" standard lock

1шт.

1913aa

1913AA

ROD, heat regulator, front, with clips. Prior to tractor no. 4400143

1шт.

nss

NSS

NOT SOLD SEPARAT

PIN, 3/32" x 5/8" cotter

1шт.

2213aa

2213AA

SHANK AND HANDLE, with snap ring, for heat regulator. Tractor no. 440143 and after

1шт.

2312aa

2312AA

BOX AND SCREEN, air cleaner.Tractor no. 4405821 and after

1шт.

nss

NSS

NOT SOLD SEPARAT

SCREW, 1/4"-28 x 3/8" fillister head machine

4шт.

2313aa

2313AA

SCREEN, chaff, air cleaner. Tractor no. 4405821 and after

1шт.

2358aa

2358AA

PIPE, air intake. Tractor no 4405821 and after. See 219AA (D, DC, DH)

1шт.
