Запчасти Case IH 560 (173) - STEERING MECHANISM, POWER STEERING, INTERNATIONAL 560 AND 660 SERIES Steering Mechanism

1

26938H

PLUG

drag link adjusting

1шт.

2

58157D

SPRING

drag link

1шт.

3

26935H

SEAT

drag link ball

2шт.

4

TUBE ASSEMBLY, drag link (not serviced separately, order drag link, 371186R91)

1шт.

5

371186R91

LINK ASSEMBLY, drag

1шт.

*

PIN, 1/8 x 1-3/4" cotter

1шт.

6

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, (Optional with 138322H) 1/8"-27 x .66 lg

1шт.

6

80710

LUBE NIPPLE,1/8” – 27 Dryseal PTF

NIPPLE, LUBE, (Optional with 109461) 1/8"-27 x .66 lg

1шт.

7

363210R1

CLAMP, drag link

1шт.

*

NUT, 1/2 NF

1шт.

*

SCREW, 1/2 NF x 2-3/4" hex-hd. cap

1шт.

*

WASHER, 1/2" lock

1шт.

8

375260R93

CYLINDER AND VALVE ASSEMBLY, (for components see list of parts under details of "cylinder and valve")

1шт.

*

PIN, 1/8 x 1" cotter

2шт.

9

364839R1

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, hose

2шт.

10

371196R92

HOSE, return (3/8" ID x 28" long)

1шт.

11

371195R92

HOSE ASSY.

HOSE, pressure (3/8" ID x 26" long)

1шт.

12

371188R22

BRACKET ASSEMBLY, cylinder anchor

1шт.

*

SCREW, 5/8 x 2-1/2" hex-hd. cap

2шт.

*

SCREW, 3/4 x 1-1/2" hex-hd. cap

1шт.

13

372790R21

TUBE ASSEMBLY, pressure

1шт.

*

SCREW, 5/16 x 1-1/4" hex-hd. cap

2шт.

*

WASHER, 5/16" lock

2шт.

14

252738R1

O-RING,0.103" Thk x 0.362" ID, -110, Cl 5, 75 Duro

pressure tube flange (3/8 x 9/16 x 3/32")

1шт.

15

371194R1

CLAMP, tube

1шт.

*

SCREW, 1/4 NF x 3/4" hex-hd. cap

1шт.

*

WASHER, 1/4" lock

1шт.

16

371192R11

BRACKET ASSEMBLY, tube support

1шт.

*

SCREW, 3/4 x 1-3/4" hex-hd. cap

1шт.

*

WASHER, 3/4" lock

1шт.

17

371191R21

TUBE ASSEMBLY, return 0.375" OD, 29.23, 5.48" Length

1шт.

18

252221R1

O-RING, power steering adapter (9/16 x 3/4 x 3/32") (unit B, C D)_

1шт.

18

252739R1

O-RING,0.103" Thk x 0.487" ID, -112, Cl 5, 75 Duro

power steering pump adapter (1/2 x 11/16 x 3/32") (units B, C and D) (used with adapter, 375416R91)

1шт.

19

372065R91

ADAPTER ASSEMBLY, power steering pump (for components see list of parts under details of "power steering adapter") (units B, C and D) (order adapter, 375416R92)

1шт.

19

375416R92

ADAPTER ASSEMBLY, power steering pump (units B and D) (for components see list of parts under details of "power steering pump adapter")

1шт.

*

SCREW, 7/16 x 1-5/8" hex-hd. cap (4 for units B and D)

1шт.

*

SCREW, 7/16 x 1-3/8" hex-hd. cap (4 for unit C)

1шт.

20

252483R1

O-RING,-218, 70 Duro, 1.234" ID x .139" Thk

pump adaptor suction port (1-1/4 x 1-1/2 x 1/8") (units B, C and D)

1шт.

22

371543R2

GASKET

power steering pump

1шт.

23

372066R1

COUPLING, pump adaptor (units B, C and D) (used only with adapter, 372065R91)

1шт.

24

371544R1

O-RING,0.07" Thk x 0.551" ID, -15, Cl 5, 75 Duro

power steering pump (9/16 x 11/16 x 1/16")

1шт.

25

370924R92

PUMP

ASSEMBLY, power steering (Thompson) (for components see list of parts under details of "power steering pump") (optional with 371135R92)

1шт.

25

1949250C1

REMAN-HYD PUMP

Reman for New P/N 370924R92

1шт.

25

1949251C1

CORE-HYDRAULIC PUMP

Return Number

1шт.

*

371803R1

BOLT,Hex, 3/8" - 16 x 2 1/2"

power steering pump

4шт.

25

371135R92

PUMP

ASSEMBLY, power steering (Cessna) (for components see list of parts under details of "power steering pump") (optional with 370924R92)

1шт.

25

1949250C1

REMAN-HYD PUMP

560 INTERNATIONAL DIESEL, 560 INTERNATIONAL GAS, Both (1/58-12/63), 660 INTERNATIONAL DIESEL, 660 INTERNATIONAL GAS, Both (1/59-12/63), All TRACTOR, ASSEMBLY, power steering (Cessna), 560 AND 660 SERIES

1шт.

25

1949251C1

CORE-HYDRAULIC PUMP

Return Number

1шт.

*

371801R1

BOLT, power steering pump short

3шт.

*

371803R1

BOLT,Hex, 3/8" - 16 x 2 1/2"

power steering pump long

1шт.

26

364839R1

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, 3/8" OD tube fitting

1шт.

7

9410202

HYD CONNECTOR,9/16"-18, 37 Degree x 9/16"-18, O-Ring

CONNECTOR, 3/8" tubing (o-ring type)

1шт.

28

372067R1

COVER, implement pump pressure port (units B, C and D)

1шт.

*

SCREW, 5/16 x 11/16" hex-hd. cap

3шт.

*

WASHER, 5/16" lock

3шт.

29

364840R1

O-RING,0.07" Thk x 0.801" ID, -19, Cl 5, 75 Duro

implement pump pressure port cover (13/16 x 15/16 x 1/16") (units B, C and D)

1шт.

30

370891R11

FLANGE ASSEMBLY, pump mounting (unit B)

1шт.

30

373714R11

FLANGE ASSEMBLY, pump mounting (unit C)

1шт.

*

SCREW, 3/8 x 1-3/8" hex-hd. cap

9шт.

*

SCREW, 3/8 x 2" hex-hd. cap

1шт.

*

WASHER, 3/8" lock

10шт.

30

372783R11

FLANGE ASSEMBLY, pump mounting (unit D)

1шт.

*

SCREW, 3/8 x 1-3/4" hex-hd. cap

9шт.

*

SCREW, 3/8 x 2-1/2" hex-hd. cap

1шт.

*

WASHER, 3/8" lock

10шт.

31

52999D

WASHER

GASKET, pump adapter bolt (4 for units B, C and D)

1шт.

32

364839R1

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, pump mounting flange plug (2 for units B, C and D)

1шт.

33

9410358

PLUG

pump mounting flange (2 for units B, C and D)

1шт.

34

363267R92

ARM ASSEMBLY, control

1шт.

35

374810R91

BRACKET ASSEMBLY, hydraulic steering cylinder (for International 660 series tractors with adjustable wide tread front axle) (not part of power steering parts accessory)

1шт.

*

NUT, 3/4 NF

2шт.

*

SCREW, 3/4 NF x 1-5/8" hex-hd. cap

2шт.

*

WASHER, 3/4" lock

2шт.

*

WASHER, 13/16 x 1-3/4" x 9 ga.

1шт.

*

366566R1

CAP

steering wheel monogrammed ("IH power steering") (illustrated with "steering mechanism")

1шт.

*

370849R1

COVER, LH valve mounting column (illustrated with "Hydra-Touch system")

1шт.

*

SCREW, 7/16 x 7/8" hex-hd. cap

4шт.

*

370801R1

GASKET

oil strainer opening cover

1шт.

*

370892R2

GASKET

pump mounting flange-light

1шт.

*

370893R2

GASKET

pump mounting flange- heavy

1шт.

*

370962R1

GEAR

pump adaptor drive (13 teeth) (unit B)

1шт.

*

373712R1

GEAR

pump adaptor drive (13 teeth) (unit C)

1шт.

*

372781R1

GEAR, pump adaptor drive (14 teeth) (unit D)

1шт.

*

NUT, 5/8 NF

1шт.

*

350667R1

O-RING,0.103" Thk x 0.674" ID, -115, Cl 5, 75 Duro

LH valve mounting column cover (illustrated with "Hydra-Touch system")

3шт.

*

370883R92

STRAINER ASSY.

STRAINER ASSEMBLY, oil

1шт.

*

370888R23

TUBE

ASSEMBLY, pump suction (unit B)

1шт.

*

372782R13

TUBE,1.755" Length

ASSEMBLY, pump suction (unit D)

1шт.

*

373710R92

TUBE

ASSEMBLY, pump suction (unit C)

1шт.
