Артикул
Название
Примечание
Количество
1
375077R91
CABLE
ASSEMBLY, glow plug meter to glow plug switch (unit B), Serial Range: 501-4099
1шт.
2
CABLE, glow plug switch to junction block (order harness, 370440R92) (unit B), Serial Range: 501-4099
1шт.
3
271179R91
SWITCH
glow plug (for components see list of parts under details of "Glow Plug Switch") (unit B), Serial Range: 501-4099
1шт.
4
370395R91
CABLE ASSEMBLY, glow plug meter to charge indicator (unit B)
1шт.
5
370375R91
IGNITION SWITCH
SWITCH, ignition
1шт.
365502R1
NUT
switch mounting
1шт.
375341R1
WASHER, 13/16" int-tooth cd-pltd. lock
1шт.
6
CABLE, ignition switch to push button switch junction (order switch, 370375R91)
1шт.
7
CABLE, ignition switch to charge indicator (order switch, 370375R91)
1шт.
8
369607R92
GAUGE
RECEIVING UNIT, electric fuel gage
1шт.
9
CABLE, fuel gage sending unit to fuel gage receiving unit (order harness, 370439R92) (unit A)
1шт.
9
CABLE, fuel gage sending unit to fuel gage receiving unit (order harness, 370440R92) (unit B)
1шт.
10
357929R92
ELECTRIC CABLE
CABLE ASSEMBLY, fuel gage to push button switch
1шт.
11
432281
HOLE PLUG BUTTON,29/32"
PLUG, cr-pltd. button (used to plug hole for cigarette lighter) 29/32"
1шт.
12
366316R91
SWITCH
push button (optional with 366317R91)
1шт.
12
366317R91
IGNITION SWITCH
SWITCH, push button (optional with 366316R91)
1шт.
NUT, no. 10 cd-pltd. sq
2шт.
SCREW, no. 10 x 3/8" rd-hd-mach. cd-pltd.
2шт.
WASHER, no. 10 cd-pltd. lock
2шт.
13
CABLE, push button switch to solenoid switch (order harness, 370439R92) (unit A)
1шт.
13
CABLE, push button switch to solenoid switch (order harness, 370440R92) (unit B)
1шт.
14
360053R92
INDICATOR
charge
1шт.
15
CABLE, charge indicator to solenoid switch (order harness, 370439R92) (unit A)
1шт.
15
CABLE, charge inidcator to solenoid switch (order harness, 370440r92) (unit B)
1шт.
16
CABLE, charge indicator to regulator "BAT" terminal (order harness, 370439R92) (unit A)
1шт.
16
CABLE, charge indicator to regulator "BAT" terminal (order harness, 370440r92) (unit B)
1шт.
17
CABLE, regulator "L" terminal to fuse holder connector (order harness, 370439R92) (unit A)
1шт.
17
CABLE, regulator "L" terminal to fuse holder connector (order harness, 370440R92) (unit B)
1шт.
18
372546R91
CABLE
SOCKET ASSEMBLY, instrument light
2шт.
371204R1
LENS
instrument light
1шт.
371205R91
SCREW, no. 8 x 3/8" cr-rec-fil-hd. w/washer
2шт.
370379R1
BRACKET, instrument light
1шт.
129934
ARM
BULB, instrument panel light (no. 57-12 volt)
2шт.
19
CABLE, fuse holder to connector (order fuse housing, 370311R91)
1шт.
20
263717R91
CLIP
cable harness (on fuel filter bracket upper LH mounting bolt)
1шт.
21
370311R91
FUSE CARTRIDGE
HOUSING ASSEMBLY, fuse
1шт.
117142
FUSE,10 Amp, Type 3AG
10 amp
1шт.
22
370439R92
HARNESS ASSEMBLY, cable (unit A)
1шт.
22
370440R92
HARNESS ASSEMBLY, cable (unit B)
1шт.
23
CLIP, on instrument panel LH side (not serviced separately)
1шт.
24
372545R91
CABLE ASSEMBLY, lighting switch to instrument light junction
1шт.
25
CABLE, lighting switch head lamp terminal to junction block (order harness, 370439R92) (unit A)
1шт.
25
CABLE, lighting switch head lamp terminal to junction block (order harness, 370440R92) (unit B)
1шт.
26
370380R92
METER
glow plug (unit B)
1шт.
27
CABLE, lighting switch tail light terminal to breakaway connector (order harness, 370442R91)
1шт.
28
371465R91
KIT
SWITCH ASSEMBLY, lighting
1шт.
29
CABLE, lighting switch rear light terminal to line connector (order harness, 370442R91)
1шт.
30
CABLE, fuse housing to lighting switch battery terminal (order housing, 370311R91)
1шт.
31
CABLE, ground to breakaway connector socket (order harness, 370442R91)
1шт.
32
370442R91
HARNESS ASSEMBLY, lighting switch to breakaway connector socket
1шт.
33
CABLE, push button switch junction to ignition coil resistor (order harness, 370439R92) (unit A)
1шт.
34
CABLE, regulator "F" terminal to generator "F" terminal (order harness, 370439R92) (unit A)
1шт.
34
CABLE, regulator "F" terminal to generator "F" terminal (order harness, 370440r92) (unit B)
1шт.
35
CABLE, regulator "Gen" terminal to generator "A" terminal (order harness, 370439R92) (unit A)
1шт.
35
CABLE, regulator "gen" terminal to generator "A" terminal (order harness, 370440R92) (unit B)
1шт.
36
REGULATOR ASSEMBLY, voltage (for components see list of parts under details of "Voltage Regulator")
1шт.
SCREW, 1/4 x 1/2" cap
2шт.
WASHER, 1/4" lock
2шт.
37
HEADLIGHT ASSEMBLY, sealed beam, RH (guide) (for components see list of parts under details of "headlight")
1шт.
NUT, 1/2NF
1шт.
38
CABLE, junction block to headlight (order harness, 370441R91)
1шт.
39
CABLE, ground to headlight (order harness, 370441R91)
1шт.
40
128157
GROMMET,3/8" ID x 27/32" x .062", Diag Cut
headlight cable harness
2шт.
41
362126R1
CLIP
cable harness (on fan housing upper RH mounting bolt)
1шт.
WASHER, 17/64 x 5/8" x .049
1шт.
42
370441R91
HARNESS ASSEMBLY, headlight
1шт.
NUT, 1/4"
1шт.
SCREW, 1/4 x 1/2" hex-hd. cap
1шт.
WASHER, 1/4" lock
1шт.
WASHER, 17/64 x 5/8" x .049 ga.
1шт.
44
372052R91
CABLE, horn (black)
1шт.
44
CABLE, horn (order harness, 370439R92) (unit A)
1шт.
44
CABLE, horn (order harness, 370440r92) (unit B)
1шт.
45
HEADLIGHT ASSEMBLY, sealed beam, LH (Dietz) (for components see list of parts under details of "Headlight")
1шт.
NUT, 1/2NF
1шт.
46
362126R1
CLIP
cable harness (on fan housing upper LH mounting bolt)
1шт.
WASHER, 17/64 x 5/8" x .049
1шт.
47
362120R1
CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type
CLIP, cable harness (on generator adjustment bolt)
1шт.
48
GENERATOR (for components see list of parts under details of "Generator")
1шт.
50
42915D
BLOCK
headlight cable junction
1шт.
NUT, no. 10
1шт.
SCREW, no. 10 x 1/2" slotted rd-hd mach.
1шт.
WASHER, no. 10 lock
1шт.
51
263514R91
CLIP
cable (on front bolt no. 5 cylinder) (unit B)
1шт.
WASHER, 13/32 x 13/16" x .065 ga.
1шт.
52
42915D
BLOCK
glow plug cable junction (unit B)
1шт.
NUT, no. 10
1шт.
SCREW, no. 10 x 1/2" slt-rd-hd. mach.
1шт.
WASHER, no. 10 lock
1шт.
53
362120R1
CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type
CLIP, cable harness (on valve cover bolts)
3шт.
55
370384R1
CLIP
cable harness and battery cable (on fuel tank support)
1шт.
SCREW, 1/4 x 1/2" hex-hd. cap
1шт.
WASHER, 1/4" lock
1шт.
56
CLIP, welded ( on fuel tank support channel)
1шт.
57
MOTOR ASSEMBLY, cranking (for components see list of parts under details of "Cranking Motor")
1шт.
58
372547R91
CABLE W/BOLT AND COVER ASSEMBLY, battery to solenoid switch (Aluminim) (gasoline) (optional with 374907R91) (unit A)
1шт.
58
374907R91
CABLE
W/BOLT AND COVER ASSEMBLY, battery to solenoid switch (copper) (gasoline) (optional with 372547R91) (unit A)
1шт.
58
370388R91
CABLE
W/BOLT AND COVER ASSEMBLY, battery to solenoid switch (Aluminim) (LP gas) (optional with 374905R91) (unit A)
1шт.
58
374905R91
CABLE
W/BOLT AND COVER ASSEMBLY, battery to solenoid switch (copper) (LP gas) (optional with 370388R91) (unit A)
1шт.
356062R91
BOLT
ASSEMBLY, terminal
1шт.
58
383012R91
CABLE
WITH BOLT AND COVER ASSEMBLY, battery to solenoid switch (unit B)
1шт.
356062R91
BOLT
ASSEMBLY, terminal
1шт.
364910R1
BOOT
COVER, solenoid terminal
1шт.
59
370376R92
GAUGE
SENDING UNIT, electric fuel gage
1шт.
369154R1
GASKET
electric fuel gage sending unit
1шт.
1310675C1
CAPTIVE WASHER SCREW,Sl Truss Hd, #10 - 24 x 0.75"
SCREW, no. 10 x 1/2" machines w/external tooth lock washer
5шт.
60
CLIP, welded (on fuel tank)
1шт.
62
CLIP, welded (on battery tray)
1шт.
63
365861R91
BATTERY (12 volt Auto-Lite 11 HS-60) (tractors equipped with L.P. gas burning engine) (unit A)
1шт.
63
368879R91
BATTERY
(12 volt Auto-Lite 11 HS-50) (gasoline) (unit A)
1шт.
63
370424R91
BATTERY (6 volt Auto-Lite 2H-135R) (2 for unit B)
1шт.
64
370394R91
CABLE
W/BOLT ASSEMBLY, battery to battery (unit B), Serial Range: 501-4896
1шт.
64
377994R91
CABLE
W/BOLT ASSEMBLY, battery to battery (unit B) 4897 up
1шт.
356062R91
BOLT
ASSEMBLY, terminal
2шт.
65
370389R91
CABLE
STRAP W/BOLT ASSEMBLY, battery to ground gasoline engine tractors, 501 to 4915 diesel engine tractors, 501 up
1шт.
65
377995R91
CABLE
STRAP W/BOLT ASSEMBLY, battery to ground gasoline engine tractors - 4916 up
1шт.
356062R91
BOLT
ASSEMBLY, terminal
1шт.
66
370740R91
CLIP, cable harness (on instrument housing support LH rear mounting bolt)
1шт.
67
355098R1
CLIP, cable harness (on hydra-touch valve support rear LH mounting bolt)
1шт.
68
355097R1
CLIP, cable harness (on LH front platform mounting bolt)
1шт.
69
362123R1
CLIP
cable harness (on fuel tank support LH rear mounting bolt)
1шт.
70
CABLE, coil positive terminal to solenoid switch "R" terminal (order harness, 370439R92) (unit A)
1шт.
72
362716R1
CLIP, cable harness (on rear frame cover LH side second bolt from rear)
1шт.
73
350742R1
CLIP, cable harness (on rear platform mounting bolt LH side)
1шт.
74
362666R1
CLIP
cable harness (on rear bolt thru fender)
1шт.
74
380053R1
CLIP, cable harness (on platform 2nd from rear mounting bolt - LH side) (tractors with full coverage fenders)
1шт.
75
CABLE, line connector to combination rear light connector (order harness, 370442R91)
1шт.
76
CABLE, breakaway connector to combination rear light connector (order harness, 370442R91)
1шт.
77
355097R1
CLIP, cable harness (on rear bolt thru fender and rear platform LH side)
1шт.
78
CABLE, breakaway connector to combination rear light connector (order harness, 370442R91)
1шт.
79
362002R92
SOCKET
ASSEMBLY, electrical breakaway connector
1шт.
NUT, 1/4"
2шт.
SCREW, 1/2 x 1-1/2" hex-hd cap
2шт.
WASHER, 1/4" lock
2шт.
61401V
SPACER, breakaway connector socket
2шт.
80
350742R1
CLIP, cable harness (thru LH fender)
1шт.
NUT, 5/16"
1шт.
SCREW, 5/16 x 3/4" hex-hd. cap
1шт.
WASHER, 5/16" lock
1шт.
81
370443R91
HARNESS ASSEMBLY, breakaway connector socket to rear light cable
1шт.
82
355097R1
CLIP, cable harness (on fender brace inner bolt LH side)
1шт.
83
REAR LIGHT AND TAIL LIGHT ASSEMBLY, combination (for components see list of parts under details of combination rear light and tail light)
1шт.
NUT, 1/2"
1шт.
84
362120R1
CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type
CLIP, cable harness (on rear light support LH mounting bolt)
1шт.
85
365503R1
SPACER
combination rear light and tail light
1шт.
86
350920R1
CLAMP
combination rear light and tail light
1шт.
87
372355R11
SUPPORT
ASSEMBLY, combination rear light and tail light
1шт.
NUT, 3/8"
2шт.
SCREW, 3/8 x 1-3/8" hex-hd. cap
2шт.
88
370307R1
SEAT
headlight mounting ball
2шт.
89
358986R1
CABLE CLIP
CLIP, cable harness (on upper LH rear of cylinder head)
1шт.
SCREW, 1/2 x 3/4" hex-hd. cap
1шт.
WASHER, 1/2" lock
1шт.
90
376533R91
CABLE ASSEMBLY, glow plug meter to glow plug switch (unit B) 4100 up
1шт.
91
374342R1
PLUG
glow plug switch mounting hole button (unit B) 4100 up
1шт.
92
CABLE, glow plug switch to junction block (black) (order harness, 370440R92) (unit B) 4100 up
1шт.
Выбрано товаров: 160
