Запчасти Case IH 460 (201[A]) - DRAWBARS & HITCHES, 3-PT INDUSTRIAL HITCH W/TEL-A-DEPTH, INTERNATIONAL 460 SERIES, MISC. PARTS Drawbar & Hitches

Схема запчастей Case IH 460 - (201[A]) - DRAWBARS & HITCHES, 3-PT INDUSTRIAL HITCH W/TEL-A-DEPTH, INTERNATIONAL 460 SERIES, MISC. PARTS Drawbar & Hitches

Артикул

Название

Примечание

Количество

370136R1

SPARE PART CLAMP, manifold tubes

2шт.

NUT, 1/4"

1шт.

SCREW, 1/2 x 1-1/8" hex-hd. cap

1шт.

SCREW, 1/4 NF x 1-1/8" hex-hd. cap

1шт.

WASHER, 1/4" lock

2шт.

9410207

HYD CONNECTOR,1 5/16"-12, 37 Degree x 1 5/16"-12, O-Ring

Return tube

2шт.

370216R1

SPARE PART Valve

1шт.

296247R1

O-RING,16-1, 90 Duro, 1.171" ID x .116" Thk

Return tube connector

1шт.

350667R1

O-RING,0.103" Thk x 0.674" ID, -115, Cl 5, 75 Duro

Valve

9шт.

355965R1

O-RING,0.139" Thk x 0.921" ID, -213, Cl 5, 75 Duro

Rear manifold flange

2шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

Valve plug

2шт.

9410360

PLUG

Valve

2шт.

370143R11

SPARE PART Manifold tubes rear

1шт.

SCREW, 7/16 x 7/8" hex-hd. cap

1шт.

WASHER, 7/16" lock

1шт.

370144R1

SPARE PART Manifold tubes - front

1шт.

SCREW, 7/16 x 2-1/4" hex-hd. cap

1шт.

370137R91

TUBE,38.697" Length

ASSEMBLY, rear manifold

1шт.

SCREW, 3/8 x 1-1/4" hex-hd.

3шт.

WASHER, 3/8" lock

3шт.

370582R11

SPARE PART ASSEMBLY, hydraulic return

1шт.

360621R94

VALVE

ASSEMBLY, regulator and safety

1шт.

Выбрано товаров: 22
