Запчасти Case IH 430 (169A) - REAR WHEELS WITH 28 INCH RIMS, POWER ADJUSTABLE, WITH JACK SCREW TYPE CLAMPS, FOUR WHEEL (06) - POWER TRAIN

Схема запчастей Case IH 430 - (169A) - REAR WHEELS WITH 28 INCH RIMS, POWER ADJUSTABLE, WITH JACK SCREW TYPE CLAMPS, FOUR WHEEL (06) - POWER TRAIN
7
25
24
11
1
19
2
20
28
16
6
23
23
29
21
10
10
17
9
35
27
15
26
22
9
30
18
3
8
4
24
5

Артикул

Название

Примечание

Количество

G12074

X

WHEEL ASSY., Includes: Ref. 1 - 10

2шт.

1

G13266

RIM - (takes 13.6 x 28 or 14.9 x 28 tire)

1шт.

2

G15440

WHEEL

DISC - wheel

1шт.

3

G15443

BODY,2" L

- jack screw

4шт.

4

111-600

BOLT - jack screw body (5/8 x 1/2" x N.C. carr.)

8шт.

5

192-25

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

8шт.

6

129-107

NUT,5/8"-11, G5

8шт.

7

G15444

JACK SCREW,7/8" - 14 x 2.85"

- jack

4шт.

8

G15445

NUT

- lock, jack screw

4шт.

9

G15441

X

LUG - rim stop

2шт.

10

A9440

STOP

SCREW - lock, stop lug

2шт.

11

A38208

WHEEL BOLT,5/8-18 UNF Class 2A

BOLT - disc to hub (5/8 x 1" N.F. special), Start Serial: 8329561

16шт.

11

B18264

WHEEL BOLT

BOLT - disc to hub (9/16 x 1-5/32" N.F. special), Serial Range: -8329561

16шт.

G12074

X

WHEEL ASSY., general purpose, Includes: Ref. 15 - 24

2шт.

15

G13266

RIM - (takes 13.6 x 28 or 14.9 x 28 tire), general purpose

1шт.

16

G15440

WHEEL

DISC - wheel, general purpose

1шт.

17

G15443

BODY,2" L

- jack screw, general purpose

4шт.

18

111-600

BOLT - jack screw body (5/8 x 1-1/2" N.C. carr.), general purpose

8шт.

19

192-25

LOCK WASHER,5/8"

WASHER, LOCK, , General purpose 5/8"

8шт.

20

129-107

NUT,5/8"-11, G5

General purpose 5/8"-11, G5

8шт.

21

G15444

JACK SCREW,7/8" - 14 x 2.85"

- jack, general purpose

4шт.

22

G15445

NUT

- lock, jack screw, general purpose

4шт.

23

G15441

X

LUG - rim stop, general purpose

2шт.

24

A9440

STOP

SCREW - lock, stop lug, general purpose

2шт.

25

A38213

HUB - rear wheel (for 5/8" N.F. bolt), general purpose, Start Serial: 8329561

2шт.

25

G1087

X

HUB - rear wheel (for 9/16" N.F. bolt), general purpose, Serial Range: -8329561

2шт.

26

G10841

BOLT

BOLT - hub, inner (3/4 x 4-1/2" N.F. hex.), general purpose

4шт.

27

G10840

BOLT

- hub, outer (3/4 x 3-3/4" N.F. hex.), general purpose

4шт.

28

193-35

LOCK WASHER,Int Tooth, 3/4"

WASHER, LOCK, Int Tooth, 3/4"

8шт.

29

G10842

NUT

- hub bolts (3/4" N.F. hex.), general purpose

8шт.

30

A38208

WHEEL BOLT,5/8-18 UNF Class 2A

BOLT - disc to hub (5/8 x 1" N.F. special), general purpose, Start Serial: 8329561

16шт.

30

B18264

WHEEL BOLT

BOLT - disc to hub (9/16 x 1-5/32" N.F. spec.), general purpose, Serial Range: -8329561

16шт.

35

G15024

WRENCH - screw jack, general purpose

1шт.

Выбрано товаров: 33
