Запчасти Case IH 430 (120) - HYDRAULIC PUMP DRIVE, STANDARD CLUTCH ASSEMBLY (08) - HYDRAULICS

1

G10422

OIL SEAL

OIL SEAL - drive housing

1шт.

2

G14468

HOUSING

- hydraulic pump drive

1шт.

3

13-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd

3шт.

4

92-6

LOCK WASHER,3/8"

3шт.

5

A27089

SNAP RING,2.36mm Thk, Ext

SNAP RING - rear

1шт.

6

G13075

BEARING, BALL

BEARING

1шт.

7

G10383

BEARING CAP

CAP - bearing retainer

1шт.

8

G10382

LOCK

- bearing cap

1шт.

9

13-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

3шт.

10

92-5

LOCK WASHER,5/16"

3шт.

11

G10407

GASKET

- housing

1шт.

12

A35083

GEAR WHEEL

GEAR - drive

1шт.

13

G13816

OIL SEAL

OIL SEAL - drive gear

1шт.

A36962

PLATE

- pressure, complete (incl. following), Includes: Ref. 15 - 24, standard clutch assembly

1шт.

A36962R

REMAN-CLUTCH PLATE

430, 530 Utility Trac., Both SN 8262800 To 8297800

1шт.

A36962C

CORE-CLUTCH PLATE

Return Number

1шт.

15

NSS

NOT SOLD SEPARAT

BRACKET AND HUB, standard clutch assembly

1шт.

16

G46061

CLIP

- clutch return, standard assembly

3шт.

17

G47010

LEVER

standard clutch assembly

3шт.

18

A40205

X

SCREW - adjusting, standard clutch assembly

3шт.

19

G49005

NUT - jam, standard clutch assembly

3шт.

20

G49048

WASHER

standard clutch assembly

3шт.

21

G47013

SPRING

- lever (white), standard clutch assembly

6шт.

22

G47012

CUP - spring, standard clutch assembly

6шт.

23

G47011

PIN

- pivot, standard clutch assembly

3шт.

24

G4506

PLATE

- pressure, standard clutch assembly

1шт.

25

G11207

BOLT

- pressure plate to flywheel, standard clutch assembly

6шт.

26

92-5

LOCK WASHER,5/16"

standard clutch assembly 5/16"

6шт.

27

A36414

PLATE ASSY.

PLATE - driving (gas engine), standard clutch assembly

1шт.

28

NSS

NOT SOLD SEPARAT

RIVET, standard clutch assembly

18шт.

29

A36036

PLATE

- driving (diesel engine), standard clutch assembly

1шт.

30

A36149

KIT

FACING KIT - driving plate, standard clutch assembly

1шт.
