Запчасти Case IH 430 (150) - ELECTRICAL SYSTEM, PRIOR TO S/N 8262800, 430 MODEL, 188 DIESEL ENGINE (04) - ELECTRICAL SYSTEMS

Схема запчастей Case IH 430 - (150) - ELECTRICAL SYSTEM, PRIOR TO S/N 8262800, 430 MODEL, 188 DIESEL ENGINE (04) - ELECTRICAL SYSTEMS
6
28
21
11
4
32
12
41
30
14
26
46
13
45
7
38
29
39
37
22
5
1
15
40
25
16
18
10
24
42
23
16
19
33
36
43
3
17
35
31
20
2
34
27
9
6
44

Артикул

Название

Примечание

Количество

1

1M-105R

BATTERY - 6 volt

2шт.

2

G13150

PAN - battery

1шт.

3

182-506

SCREW - 5/16" x 1/2" Philips recessed (Spin Lock)

4шт.

4

111-213

CARRIAGE BOLT,Short NK, 5/16"-18 x 9", G2

BOLT - 5/16" x 9" rd. hd. sq. neck

2шт.

5

G46096

RETAINER

BUSHING - rubber, bolt retaining

2шт.

6

G13205

FRAME - hold down, battery

1шт.

7

G49020

NUT

- hold down bolt (5/16" N.C. wing)

2шт.

8

95-5

WASHER,3/8" x 7/8" x .083"

- 5/16" plain

2шт.

9

VT2336

X

STRAP - ground (Before SN8233766)

1шт.

9

A36368

STRAP

- ground (SN 8233766 and after)

1шт.

10

G13098

CABLE

- jumper, Serial Range: battery-battery

1шт.

11

O6362AB

X

COVER - battery terminal

4шт.

12

G44049

CABLE

- battery to solenoid (Before SN8233766)

1шт.

12

O9999AB

X

CABLE - battery to solenoid (SN8233766 and after)

1шт.

13

A21753

CAP

NIPPLE - solenoid terminal

1шт.

14

G44927

STARTING MOTOR - (Delco #1107516) Order A36583

1шт.

14

A36582

STARTING MOTOR - (Delco #1107584) Order A36583

1шт.

15

A36583

STARTER MOTOR

STARTING MOTOR - (Delco #1107583) For starting motor repairs see Figure 156

1шт.

15

413-632

BOLT,Hex, 3/8" - 16 x 2", Gr 5

3шт.

16

A21481

SOLENOID

- manifold heater plug

1шт.

17

G44053

X

CABLE -, Serial Range: solenoid-solenoid

1шт.

18

G30577

BRACKET - solenoid (w/Power Steering)

1шт.

19

G44067

CABLE - heater (Before eng. #2028232)

1шт.

20

G15955

BAR

- heater connecting (Before eng. #2028232)

1шт.

21

G45259

PLUG

- heater (Before eng. #2028232)

4шт.

22

131-972

NUT

- lock, #10-32 (Before eng. #2028232)

4шт.

23

A24396

X

PLUG - heater (Eng. #2028232 and after) (incl. ref. 24)

1шт.

24

129-503

NUT,1/4"-20, Brass

1шт.

25

A20916

MANIFOLD GASKET

GASKET - plug (Eng. #2028232 and after)

1шт.

26

A21482

CABLE

- solenoid to heater (Eng. #2028232 and after)

1шт.

27

G44877

GENERATOR - (Delco #1100385) Order A36563

1шт.

27

A36563

GENERATOR

- (Delco #1100443) Repairs Figure 154

1шт.

28

13-516

BOLT,Hex, 5/16" - 18 x 1", Gr 5

2шт.

29

G2131

X

BRACKET - generator mounting

1шт.

30

13-516

BOLT,Hex, 5/16" - 18 x 1", Gr 5

1шт.

30

13-522

BOLT,Hex, 5/16" - 18 x 1-3/8", Gr 5

- 5/16 x 1-3/8" N.C. hex hd.

1шт.

31

G2098

SUPPORT - gen. bracket (w/o Power Steering)

1шт.

32

13-652

BOLT,Hex, 3/8" - 16 x 3-1/4", Gr 5

- 3/8" x 3-1/4" N.C. hex hd.

3шт.

33

VT3691

X

GASKET - support

1шт.

34

G37017

KIT

STRAP - adjusting, generator

1шт.

35

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

1шт.

36

13-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

1шт.

37

G46238

BELT,0.55" W x 17.78" L

Fan and Generator Drive 0.55" W x 17.78" L

1шт.

38

G44061

CABLE - master, lower half

1шт.

39

G44060

HARNESS

CABLE - master, upper half

1шт.

40

G44889

X

REGULATOR - voltage (Delco #1119267) Use only with positive ground generator G44877 Order when depleted

1шт.

40

A35233

REGULATOR

- voltage (Delco #1119241)

1шт.

41

14-424

SCREW,Hex, 1/4" - 28 x 1 1/2", Gr 5

BOLT - 1/4" x 1-1/2" N.F. hex hd.

4шт.

42

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex hd.

4шт.

43

G44066

CABLE

- safety starting switch

1шт.

44

F46047

CLIP - wire

1шт.

45

A20990

SWITCH

- safety, neutral start

1шт.

46

G44875

LIGHT

- warning, generator

1шт.
